Signboard Wall Video Advertising Led Display Screen Outdoor P4 3 Years Warranty

Brand Name:	SCXK
Model Number:	P4
MOQ:	1 sqm
Price:	negotiation
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ROHS/FCC/ISO/UL

Pixel Pitch:

4mm

Pixel Configuration:

SMD 3-IN-1

Pixel Density:

62500dots/m2

Module Size:

256x128mm

Cabinet Material:

Die Casting Aluminum

Brightness:

≥7000cd/m2

Driving Mode:

1/8 Scan

Warranty:

3 Year

Packaging Details:

wooden case or flight case are available.

Highlight:

advertising led display board

outdoor advertising led display

Product Description

China Manufacturer high bright outdoor led display big screen p4 led display/TV/signboard/wall video

Product Features
1) Reliable quality, advanced and mature technology, compliant with industrial standards and technology developing trend.
2) Good heat emission, water proof and stable performance.
3) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal.
4) High resolution and definition of screen image, clear and non-flash screen image.
5) Supports video and radio frequency input, special structure can be freely assembled.

Module Parameter

Pixel pitch	4mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD 3535
Module size	256x128mm
LED lamp	KingLight or Nationstar
Module resolution	64x32dots
Module quantity per cabinet	8pcs

Cabinet Parameter

Cabinet size	512x512mm
Cabinet material	die casting aluminum
Cabinet weight	9kg
Ingress protection	Front/Rear IP65/IP54

Whole Screen Parameter

Pixel density	62500 dots/m²
Brightness	≥7000 cd/m²
Viewing angle	H≥120° V≥120°
Min.viewing distance	4m
Max.power consumption	1000W/m²
Avg.power consumption	480 W/m²
Working voltage	110~220VAC±15%
Interface	HUB75
Colors	16.7millon colors
Gray level	14-16bits
Frame frequency	≥60frames/s
Refresh rate	≥600Hz
MTBF	≥10000 hours
Lifespan	≥50000 hours
Protective function	Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc.
Operating temperature	-10℃ ~ +40℃
Operating humidity	10-80% no condensation
Storage temperature	-20℃ ~ +60℃
Storage humidity	10-85% no condensation

Control System Parameter

Video signal (with video processor)	AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature	Adjustable by software
Brightness level	256 levels, automatic adjustment by software
Control way	Computer, video-synchronous, real-time, off-line, wireless, internet etc.

Cabinet detials
Signboard Wall Video Advertising Led Display Screen Outdoor P4 3 Years Warranty 0

Product item
Many other hot product, welcome to visit our company!

Company profile

Certificate

Packaging and shipping
Shipping by sea,air or DHL,multiple shipping ways for your choice.

Our service

Warranty
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!

Delivery time
1.Delivery time, Accompalish manufacturing within 25 days after receiving the deposit.
2.Before Delivery, we will test the display , and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.

Installation
1.We can assist the training and technical support for the customer in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need
