Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P6.67 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Pixels: | 6.67mm | Usage: | Outdoor |
|---|---|---|---|
| Screen Dimension: | Customized | Tube Chip Color: | Full Color |
| Display Function: | Video | Brightness: | 5500nits |
| Warranty: | 2-3 Years | Life Span: | 100000hours |
| Scan Mode: | 1/8 Scan | Cabinet Material: | Iron Or Aluminum |
| Highlight: | full color led signs outdoor,full color outdoor led display |
||
P6.67 Outdoor Full Color LED Display High Quality Video Panel IP65
Features:
1: Adopting Taiwan Epistar's large LED chip, the brightness is more than 5500nits;
2: High Color Output: 16-bit color, so the video and images displayed on the LED screen are very fresh and vivid.
It can attract more viewers' eyes and make your advertisement very effective.
3: High refresh rate, more than 3840HZ/S; no scan lines when taking photos or videos.
4 High waterproof function: IP65 on the front side, IP54 on the back side. Our cabinet has a special cover on the back door, no need
to make an extra frame to protect the back side waterproof.
Specifications:
| SMD P6.67 | |||||
| Resolution/mm | 6.67 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 22478dots/square meter | ||||
| Module resolution | 48x24mm | ||||
| Module size/mm | 320x160mm | ||||
| View distance | 7-50m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 5500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 1200Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
