Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | CHINA |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | SMD P2.5 |
| Minimum Order Quantity: | 21 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 5-12 working days |
| Payment Terms: | L/C, D/P, Western Union, T/T, D/A, MoneyGram |
| Supply Ability: | 4100 sqm month |
| Application: | Indoor Video | Color: | Full Color |
|---|---|---|---|
| Panel Size:: | 320x160mm | Product Name::: | P2.5 Indoor Led Display |
| Refresh Rate::: | 1920Hz-3840Hz | Scan Mode::: | 1/32 Scan |
| Certificate::: | CE ROHS FCC CCC ISO9001 | Cabinet Size::: | 640x640mm |
| Cabinet Material::: | Die-casting Aluminum | ||
| High Light: | led full color screen,indoor led display screen |
||
640x640mm rental panel 3840Hz high refresh Kinglight SMD full color super thin led display screen p2.5 indoor
Product Features:
♦ Product specification
| Lamp size | 2121 | |||||
| Resolution/mm | 2.5 | |||||
| Pixel configuration | RGB 3 in 1 | |||||
| Pixel density/pixels/m² | 160000/m² | |||||
| Module resolution | 64x32 | |||||
| Module size/mm | 160x160 | |||||
| View distance | ≥1m | |||||
| Single point brightness adjust | Can be added | |||||
| Single point color adjust | Can be added | |||||
| White balance brightness | >2500cd/㎡ | |||||
| Color temperature | 6500K-9500K | |||||
| Horizontal view angle | 120(degrees) | |||||
| Vertical view angle | 60(degrees) | |||||
| Signal Process bit | 10 or 14 bit | |||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | |||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km | |||||
| Driving mode | Constant driving current | |||||
| Scanning mode | 1/32 | |||||
| Frame rate | 60Hz | |||||
| Refresh frequency | >4200Hz | |||||
| Control mode | Computer synchronous | |||||
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
|||||
| Out of control point | <1/10000 | |||||
| Working hours | ≥72hours | |||||
| Mean Time Between Failure | >5000hours | |||||
| Life time | 100000hours | |||||
| Life-all-white(brightness halving) | 50000hours | |||||
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range: -30-65℃ | |||||
| Maximum power:/㎡ | <1100W | |||||
| Average power:/㎡ | <280W | |||||
| Self-check technology |
LED spot self-check, communications check, power check, temperature monitor(need customization) |
|||||
| Remote monitoring |
Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
|||||
| Software environment | WindowsNT,Windows1999,WindowsXP | |||||
| Luminous point width between centres | Deviation<3% | |||||
| Brightness uniformity | <10% | |||||
| Color uniformity(chromaticity coordinate) | ±0.003 | |||||
| Power supply request | AC85-264V(50Hz-60Hz) | |||||
| Contrast | (1000:1) | |||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | |||||
| Humidity(working) | working:10-95% | |||||
| Humidity(storing) | storing:10-95% | |||||
Product Overviews
| Items | Indoor Led display: P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10 Outdoor Led display: P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25 |
| Material | steel,aluminum ,die casting aluminum |
| Payment terms |
30% deposit before production, 70% balance before shipping |
| T/T | |
| Western Union | |
| Packing: | Standard Export Carton with fully Polyfoam or Pearl Wool |
| Flight case; | |
| Anti-shaking wooden case | |
| Shipping: | 5 to 7 working days upon receiving deposit payment |
| After-Sales-Service: | Lifetime with professional engineer support for free. |
| Within 5 year, supply spare parts for free if has quality problem ( not by man-made damage) |
|
| Using Range | Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi,and so on. |
Our case
♦ Features
1. Fast Installation
Standard cabinet size: 640X640MM Cabinet weight is only 6kg/pcs Auto-lock system for fast & easy installation Cost and time saving with LED unique cabinet.
♦ Applications
LED display can be widely used in advertising,multi-media,stadium,stage,rental show,transit directions,etc.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
FAQ
Q1: Are you the manufacturer or trading company? and where is your factory?
A: We are professional manufacturer. You are warmly welcome to visit our factory to learn the technical and maintenance skills and
everything you need in our factory.
Q2:May be we will need some samples, what is the lead time of samples and lead time of order?
A2:We will arrange your sample of the charges within 7 days and arrange your order within 12-15 days after receiving ur salary.
Q3:How could us arrange order?
A:Please send your inquiry to us--click the "send" in below, then let us confirm all details, u can click "start order" in above,
or we send you order link for your payment.
Q4:Which payment method does your company accept?
A:We support T/T or Trade Assurance. For more payment methods, please contact our customer service.
Q5:If have quality problems, how do you solve them?
A:Please provide relevant videos and photos within 1 month of receipt of the shipment. We will verify it at first. If it is really quality problem, we will work with the engineer to assist u in solving the problem. If we can't solve it, we will give you a refund or resend you new one for free, but we will not bear the freight.
