Product Details:
Place of Origin: CHINA
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SMD P4
Payment & Shipping Terms:
Minimum Order Quantity: 6 sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 5-12 working days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 6500 sqm month
Contact Now
Detailed Product Description
Type:: P4 Led Video Wall Panel Certificates:: CE,CB,IECC ,FC
Led Lamp:: SMD2121 Model Number:: P4 Led Video Wall Panel
Brightness:: ≥1800cd/m2 View Angle(H/V):: H≥120°,V≥120°
Panel Size:: 256*128mm Life Span:: 100000 Hours
High Light:

led display smd

,

smd led display

P4 512*512mm SMD2121 Indoor LED Display Screen Die Casting Aluminum Cabinet Video Wall Rental LED Advertising Billboard



indoor SMD P4
Lamp size 2121
Resolution/mm 4
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 62500/m²
Module resolution 32x32
Module size/mm 256x128
View distance ≥4m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1800cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 120(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/16
Frame rate 60Hz
Refresh frequency >1200Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <1100W
Average power:/㎡ <280W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s 0P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s 1P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s 2

1. High definition small pixel pitch, suitable for indoor short distance vision
2.Ultra slim well-formed cabinet;

3. Easier for insallation and maintenance

4. SMD 3-in-i technology, big visual angel, no deformation of pictures

5.Fast heat dissipation

6. Support fixed and rental movable led display

7. True color high definition HD video display.

8. Different cabinet style for choice, rental alumnium or customized cabinet. With your logo printed on the cabinets.



♦ Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping
Wooden case or flight case package are available.



Trade info

1).Trade terms: FOB,CIF,EXW

2).Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery

4).Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days. Sample can be deliveried within 3days
5).Shipping: by sea,by air and by express delivery
6).Shipping port: Shenzhen, Mainland China



FAQ



1. How long could i receive the inquiry reply ?
A: You will get a reply within 12 hours

2.How to proceed an order for led display?
A:Firstly let us know your requirements or application
Secondly we quote according to your requirements or our suggestions.
Thurdly customer confirms the design document and places deposit for formal order.
Fourthly we arrange the productio

3.What kind of led display do you offer ?
A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty

4.How long will it take to deliver goods ?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment5.How is the after sales service ?
A: We have a professional team which is in all around the world , also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems
