Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration

Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration

  • Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration
  • Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration
  • Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration
Outdoor HD Full Color Stage LED Screens RGB 3 In 1 Pixel Configuration
Product Details:
Place of Origin: CHINA
Brand Name: SCXK
Certification: CB/CE/ROHS/FCC/ISO/UL
Model Number: SMD P4.81
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 sqm month
Contact Now
Detailed Product Description
Lamp Size: 2121 Resolution/mm: 4.81
Pixel Configuration: RGB 3 In 1 Pixel Density/pixels/m²: 65410/m²
Module Resolution: 64x64 Module Size/mm: 500x500
View Distance: ≥2m Scanning Mode: 1/16
Refresh Frequency: >4200Hz
High Light:

led stage display

,

stage background led screen

P4.81 hot outdoor HD full color stage LED screen leads the background of the live event, 3840hz refresh rate


Stage rental LED display screen
LED rental screens can easily installed and removed, also easy to transport.LED rental screens now are widely used in stage show, concert,theater, party,and other entertainment event as background, it can be live show and replay,and its so big that audience far away from the stage can see the performance on the stage clearly, creating a magnificent , highly infectious atmosphere, combined with highquality sound, giving a perfect visual feast.

HD indoor full color led display screen Indoor Rental Full Color LED video wall

1, Vivid and exact picture, minimum noise, advanced test equipment, support any pc operation system and play a variety of information likevideo, word, flash, music, clock, graph etc.
2, High brightness and support brightness automatically adjustment.
3, Long lifespan, can reach more than 100,000 hours, while the power consumption is lower than one tenth of lamp or neon;
4, Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system;
5, Rich indoor full color LED display board engineering experience both in domestic and international market.
6, Applied to place where requires high-definition display ,such as Indoor stage, television studio, concert, exhibition etc.
Product specification

indoor SMD P4.81
Lamp size2121
Resolution/mm4.81
Pixel configurationRGB 3 in 1
Pixel density/pixels/m²65410/m²
Module resolution64x64
Module size/mm500x500
View distance≥2m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>2500cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/16
Frame rate60Hz
Refresh frequency>4200Hz
Control modeComputer synchronous
Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡<1000W
Average power:/㎡<280W
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)storing:10-95%


Product Overviews

ItemsIndoor Led display:
P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
Outdoor Led display:
P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
Materialsteel,aluminum ,die casting aluminum
Payment
terms
30% deposit before production, 70% balance before shipping
T/T
Western Union
Packing:Standard Export Carton with fully Polyfoam or Pearl Wool
Flight case;
Anti-shaking wooden case
Shipping:5 to 7 working days upon receiving deposit payment
After-Sales-Service:Lifetime with professional engineer support for free.
Within 5 year, supply spare parts for free if has quality problem
( not by man-made damage)
Using RangeShopping mall,bank,bus station, train station,
center of downtown, airport, school, factory, bus, taxi,and so on.


Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
Features
1. Seamless --- precision cabinet, light weight and more durable.
2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. High refresh rate and high gray scale --- to ensure color consistency and better images
Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Our team will be forever here to offer you full supports
