Place of Origin: | CHINA |
Brand Name: | SCXK |
Certification: | CB ,CE,ROHS,FCC,SASO |
Model Number: | SMD P10 |
Minimum Order Quantity: | 12 SQM |
---|---|
Price: | negotiation |
Packaging Details: | flight case,wooden case ,it is up to you. |
Delivery Time: | 3-12 working days |
Payment Terms: | L/C, D/P, D/A, T/T, Western Union, MoneyGram |
Supply Ability: | 3900 sqm month |
Application:: | Outdoor Advertising, Outdoor Indoor Advertising | Color:: | RGB256 |
---|---|---|---|
Panel Size:: | 320*160mm | Pixel Pitch:: | 10mm |
Display Function:: | Video | Brightness:: | 6500cd/sqm |
Life Span:: | 100000 Hours | Pixel Density:: | 10000dots/m2 |
Module Resolution:: | 32*16 | Certificate:: | CE ROHS FCC |
Modules Dimension:: | 320*160mm | ||
High Light: | full color led signs outdoor,outdoor full color led screen |
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM,any your customized lightings we can help you to design and put into product
3)Distributoer ship are offered for your unique design and some our current models
4)Protection of your sales area,ideas of design and all your private information
5)Two years warranty for the whole system except human factor and force majeure
6)One year quality warranty, lifetime maintenance, and guarantee the maintenance time in contract.
7)During the warranty period: solve problems for users through the phone, fax or E-Mail. Update the software free of charge.
1)Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.
2)Adopt top high brightness with low power consumption LED lamp,energy saving≥30%, if adopt 28 kinds of main patent technique, entire energy saving ≥50%, environment protection.Pioneer in outdoor mature HD LED Display, all advanced specifications 2 years earlier than others, successful cases around the world.
3)Adopt dual service of black kingkong series among core techniques, free back service path for all kinds of installation surroundings.Broadcast level color scale, color temperature and brightness adjustable intelligentizedly, smooth color, high color ratio, nature pictures.
Specifications
Unit Module | Item | Parameter | Parameter |
Module number | P10 | P8 | |
Moule size | 320mm x 160mm | 256mm x 128mm | |
Pixel pitch | 10mm | 8mm | |
Pixel density | 10000dots/sqm | 15625dots/sqm | |
Pixel configuration | 1R1G1B | 1R1G1B | |
Package mode | smd 3535 | smd3535 | |
Pixel resolution | 32x 16 dots | 32x16dots | |
Max power consumpion | 28w | 28w | |
Module thickness | 14.85mm(without magnet) | 14.85mm(without magnet) | |
27.15mm(with magnet) | 27.15mm (with magnet) | ||
Module weight | 0.504kg | 0.7kg | |
Driver method | constant drive | constant drive | |
Driver method | 1/4 scanning | 1/4 | |
Port type | HUB75 | HUB75 | |
Brightness | >7000cd/sqm | >7000cd/sqm | |
Bracket | Size | 320mm x 160mm | 256mm x 128mm |
Unit Cabinet | Cabinet size | 960mm x 960mm | 1024mm x 1024mm |
Quantity of module | 18pcs | 32pcs | |
Power supply | 5v/40A x 5pcs | 5V/40A x5pcs | |
Thermal discharge | 2pcs cooling fans | 2pcs cooling fans | |
Pixel per cabinet | 96 x 96 dots | 128x128 dots | |
Best viewing distance | 5m-100m | 5-100m | |
Best viewing angle | 160°(w)120°(H) | 160°(w)120°(H) | |
Temperature | storage:-35℃- +85℃ | storage:-35℃-+85℃ | |
working:-20℃- +50℃ | working:-20℃-+50℃ | ||
Opration humidity | 10%-95% | 10%-95% | |
Thickness | 145mm | 145mm | |
Power | Working voltage | 220V±10% | 220V±10% |
Averange power consumption | 140W/sqm | 140W/sqm | |
Max. power consumption | 420w/sqm | 420W/sqm | |
Current | <20mA(single LED) | <20mA(single LED) |
