Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCX |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | P3.91 |
| Minimum Order Quantity: | 3 SQM |
|---|---|
| Price: | USD 1000-10000 |
| Packaging Details: | Wooden Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sqm per month |
| Led Module: | 250*250mm | Pixel Pitch: | 3.91mm |
|---|---|---|---|
| Pixel Density: | 65410 Dots/sqm | Module Pixles: | 4096dots |
| Module Resolution: | 64dots × 64dots | Tube Chip Color: | Full Color |
| Highlight: | indoor led display screen,indoor led billboard |
||
Rental Curved SMD HD Full Color LED Display P3.9mm Indoor Slim LED Video Screen
Features
P2.9/P3.9/P4.8 Indoor Event Audiovisual Equipment LED Video Wall adopts multiple quick locks and positioning pins, and the flatness and seamlessness are greatly improved, with a precise seamlessness and flatness of 0.01mm. 1. Stage LED Screen: Easy to hang and install, the background video panel is assembled quickly, suitable for stage layout. 2. Conference Room LED Screen: Installed in conference rooms and board rooms as a meeting or stage background. 3. Stadium LED Screen: Installed in stadiums to broadcast live sports events, as a video wall panel 4. Conference Room and Auditorium LED Screen: Installed with portable profile aluminum structure, as a mobile LED screen. 5. Banquet LED Screen: Installed in banquet halls for music videos or event video panel settings. 6. Airport LED Screen: Installed at airports for festival advertising or special video displays.
Specification
Indoor P3.91 high resolution curve LED video wall/LED screen panel/hd LED display screen for TV studio stram video live show
| Item | Technical Specifications | ||||
| Pixel Pitch | 2.97mm | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
| LED Configuration | SMD1010 (3-IN-1) | SMD1010 (3-IN-1) | SMD1010 (3-IN-1) | SMD1010 ( 3-IN-1) | SMD2121(3-IN-1) |
| Pixel Density | 112896pixels/sqm | 65746pixels/sqm | 43264pixels/sqm | 28224pixels/sqm | 25600pixels/sqm |
| Module Size | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Cabinet Szie | 500mm*500mm/500mm*1000mm | ||||
| Cabinet Resolution | 168*168pixels | 128*128pixels | 104*104pixels | 84*84pixels | 80*80pixels |
| Cabinet Material | Die-casting Aluminum cabinet with curved design LED Display Screen | ||||
| Cabinet Weight | 7Kg curved LED Display panel cabinet | ||||
| Brightness | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm |
| Color Temperature | 3500K-9500K | 3500K-9500K | 3500K-9500K | 3500K-9500K | 3500K-9500K |
| Viewing Angle | H:160°/V:160° | ||||
| Ave Power Consumption | 230W/sqm | 230W/sqm | 230W/sqm | 230W/sqm | 230W/sqm |
| Max Power Consumption | 800W/sqm | 800W/sqm | 800W/sqm | 800W/sqm | 800W/sqm |
| Drive Mode | 1/28scan | 1/16scan | 1/13scan | 1/7scan | 1/10scan |
| Best Viewing Distance | ≥2.97m | ≥3.91m | ≥4.81m | ≥5.95m | ≥6.25m |
| Input Voltage | AC220V/50HZ or AC110V/60HZ(±10%) | ||||
| Output Voltage | 5V 40A | ||||
| Refresh Rate | ≥3840Hz | ||||
| Frame Rate | 50/60Hz/sec | ||||
| Protection Level | IP43 | ||||
| Life Span | 100,000hours | ||||
| Malfunction dot rate | <0.0001 | ||||
| Storage Temp/Humidty | —40~+60°C/10-80%RH | ||||
| Operating Temp/Humidty | —25~+50°C/10-90%RH | ||||
| Input Signal | RF,TV.RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc | ||||
| Pc Operating System | Microsoft Windows 7.8.10.98.2000.XP and Vista | ||||
Product Details
| Payment terms: |
35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
| Packing: |
-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
| Shipping: |
LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
| After-Sales-Service: |
-Lifetime with professional engineer support for free. has quality problem |
Our Service
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained
and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time
