Place of Origin: | CHINA |
Brand Name: | SCXK |
Certification: | CE,ROHS,FCC,SASO |
Model Number: | SMDP2.5 |
Minimum Order Quantity: | 16 sqm |
---|---|
Price: | negotiation |
Packaging Details: | wooden case , flight case ,it is up to you. |
Delivery Time: | 7-11 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000 sqm month |
Application:: | Indoor, Indoor Commercial Display | Color:: | FULL COLOR |
---|---|---|---|
Panel Size:: | 320X160mm | Pixel Pitch:: | 2.5mm |
Product Name:: | Led Display Panel | Cabinet Size:: | 640X640mm |
Cabinet Resolution:: | 256X256pixel | Cabinet Material:: | Die Casting Aluminum |
Brightness:: | ≥800 Nits | Average Power:: | ≤180W/m2 |
High Light: | led full color screen,indoor led display screen |
640x640mm portable cabinet front rear service high definition Kinglight SMD2020 p2.5 indoor led wall display
Product Specifications
Model | P2.5 | |||
LED Chip | Kinglight Gold | |||
LED Type | SMD 2121 | |||
LED Driver | MBI5153 | |||
Pixel Pitch | 2.5mm | |||
Module Size | 160*160mm | |||
Module Resolution | 64* 64 | |||
Drive Type | 1/32 scan | |||
Pixel Configuration | 1R1G1B | |||
Density | 160000 dots/sqm | |||
Brightness | 1000cd/sqm | |||
Gray Level Grades | RGB each 256 | |||
Colors | 16bit colors | |||
Refresh Rate | 3840 Hz | |||
Module Weight | 0.53kg | |||
Data Port | Hub75 | |||
View Angle | 130/130 | |||
Module Max Consumption | 40W/piece | |||
Module Average Consumption | 20W/piece | |||
Power supply | G-energy | |||
Working Temperature | -20℃~+75℃ | |||
weight(kg/pc) | 6.8kg/piece | |||
Modules per cabinet | 4pcs | |||
Standard cabinets size | 480*480 mm | |||
Working Humidity | 10%~90% | |||
LED Lifespan | 100,000hrs | |||
Working Voltage | AC220/AC110V | |||
Poewr Watt(MAX) | 640W/sqm | |||
Average Power | 310W/sqm | |||
Proof Grade | IP34 | |||
Certifications | CE&RoHS&FCC |
