Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCX |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | P2.5 |
| Minimum Order Quantity: | 3 SQM |
|---|---|
| Price: | USD 1000-10000 |
| Packaging Details: | Wooden Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sqm per month |
| Led Module: | 160*160mm | Pixel Density: | 160000dots/sqm |
|---|---|---|---|
| Color Temperature Condition: | 3500K～9500K,(can Be Adjustable) | Number Of Colors: | 16.7 Trillion |
| Brightness Adjustment: | 0-100% 8 Levels | Module Resolution: | 64*64 |
| Display Function: | Video,picture,Text,Graphics,animation | Brightness: | 1000 |
| Cabinet Size: | 480*480mm*68mm | ||
| Highlight: | indoor led billboard,indoor led display screen |
||
Top quality high refresh rate black SMD Indoor HD P2.5 Led Panel , Led Screen P2.5 P2 Led Video Wall For TV Studio
Features
1) Front and rear maintenance are optional, realizing front and rear maintenance of modules, power supplies, and receiving cards, saving your maintenance costs.
2) Using top-level high-brightness and low-power LED lights, energy saving ≥30%. If 28 major patented technologies are adopted, the whole machine energy saving ≥50%, green and environmentally friendly. The first outdoor mature high-definition LED display, various advanced technical indicators are 2 years ahead of the industry, and a global success case.
3) The core technology adopts the Black King Kong series dual maintenance, providing free background maintenance paths to adapt to various installation environments. Broadcast-level color gradation, color temperature and brightness are intelligently adjustable, the color is delicate, the color rendering rate is high, and the picture is natural.
Specifications
| Value | SCX 2.5 | SCX 3 | SCX 4 |
| Pixel pitch (mm) | 2.5 | 3 | 4 |
| Pixel configuration | SMD | SMD | SMD |
| Brightness (nits) | 1000 | 1000 | 800 |
| Grey scale ( level ) | 16384 | 16384 | 16384 |
| Pixel Matrix Per Panel | 192 x 192 | 160 x 160 | 120 x 120 |
| Pixel Matrix Per Sq.m | 160000 | 111111 | 62500 |
| Viewing Angle (H/V) | 160 / 160 | 160 / 160 | 160 / 160 |
| Refresh rate (Hz) | ≥1920 | ≥1920 | ≥1920 |
| IP grade ( F / R) | IP40 / IP31 | IP40 / IP31 | IP40 / IP31 |
| Input voltage ( V ) | AC220V±10% | AC220V±10% | AC220V±10% |
| Power Consumption (Max / Avg) | 490 / 170 w/sq.m | 650 / 230 w/sq.m | 500 / 150 w/sq.m |
| Size (L x W x D mm) | 480x480x67 | 480x480x67 | 480x480x67 |
| Panel weight (Kgs) | 5.1 (Die-casting Alu.) | 5.1 (Die-casting Alu.) | 5.1 (Die-casting Alu.) |
