Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | P2.5 |
| Minimum Order Quantity: | 1 SQM |
|---|---|
| Price: | USD 2000-1000 |
| Packaging Details: | Flight Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sqm per month |
| Step Pixels: | 2.5mm | LED Shape & Size: | 2.5mm SMD 2121 |
|---|---|---|---|
| Module Dimension: | 320 Mm X 160 Mm | Module Resolution: | 128 X 64 |
| Module Weight: | 0.5kg | Cabinet Size: | 640*640mm |
| Brightness: | ≥1300cd/sqm | Cabinet Size: | 480*480mm*68mm |
| Highlight: | GOB led wall display,4K indoor smd led display |
||
High Definition Popular GOB Waterproof Dustproof Dampproof 4K 8K Indoor Full Color LED Screens
Product Advantage
1. The back of the module is plated with conformal coating to ensure that the GOB led screen is waterproof
2. The GOB led screen is moisture-proof and can effectively prevent more than 85% of dead light problems.
3. The front of the module is plated with special materials to protect the LED from collision, so the GOB led screen has anti-collision function.
4. The GOB led screen can be used indoors or outdoors.
5. It looks like an acrylic sheet covering the module, which can effectively prevent the LED lights from being hit.
6. The GOB led screen can be used for rental or fixed.
Pamameter
| Module Parameters | |||||
| Pixel Pitch | 2.5mm | ||||
| Pixel Configuration | 1R1G1B | ||||
| Density | 160000 pixels/sqm | ||||
| LED Lamp | SMD2121 | ||||
| Module Size | 320*160mm | ||||
| Module Resolution | (W)128Pixels * (H)64Pixels | ||||
| Working Voltage | DC5V | ||||
| Scan Mode | 1/32 Scan | ||||
| Drive IC | MBI 5124(Can be customized) | ||||
| Port Type | HUB75 | ||||
| Screen Parameters | |||||
| Cabinet Size | (W)640*(H)640mm | ||||
| Cabinet Material | Die-casting aluminum | ||||
| Cabinet Weight | 5.76KG | ||||
| Cabinet Resolution | 256*192 Pixels | ||||
| Module Qty | 8 pcs | ||||
| Power Supply | 200W | ||||
| Working Voltage | AC220V±10% | ||||
| Max Power Consumption | 600W/sqm | ||||
| Ave Power Consumption | 200W/sqm | ||||
| Brightness | 800 Nits | ||||
| Refresh Rate | 1920Hz/ 3840Hz | ||||
| Frame Frequency | 60Hz | ||||
| Grey Scale | 14 bit | ||||
| Brightness Level | 256 levels | ||||
| Best View Distance | 2.5M-50M | ||||
| View Angle | 120°(Horizontal); 120°(Vertical) | ||||
| Protection Degree | IP30 | ||||
| Working Temperature | -20℃ ~ +60℃ | ||||
| Relative Humidity | 10%-95% | ||||
| Operation system | WIN7/WIN8 | ||||
| Control Method | Synchronous or Asynchronous | ||||
| Control System | NovaStar | ||||
| Receiving Card | MRV336 | ||||
| Control Distance | 100M(Ethernet cable); 20KM(Optical fiber cable) | ||||
| Input Signal | Composite Video, S-video, DVI, HDMI, SDI, HD-SDI | ||||
| Out-of-Control Pixel Rate | ≤0.01% | ||||
Detailed Picture
load testing for GOB led screen P2.5
Its not dance floor led screen.
Only to prove that our film coating technology is good enough to bear over 50kg weight .
Our Service
1) Your inquiry about products or prices will be responded within 24 hours 2) OEM and ODM, we can help you design any customized lamps and put them into products 3) Provide distribution rights for your unique designs and some of our current models 4) Protect your sales area, design ideas and all private information 5) Top quality + reasonable price + responsible after-sales service = success and victory
