Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification

Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification

  • Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification
  • Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification
  • Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification
Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE,ROHS,FCC,SASO,BIS,ISO-9001
Model Number: P5
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: Flight Case , 700*700*380mm
Delivery Time: 3-5 Working Days
Payment Terms: Western Union,, T/T
Supply Ability: 3,000 sqm per Month
Contact Now
Detailed Product Description
Module Size: 320x160mm Pixel Pitch: 5mm
Module Resolution: 64x32 Driving Mode: 1/8
Brightness: ≥6000cd Color Temperature Condition: 3500K~9500K,(can Be Adjustable)
Number Of Colors: 16.7 Trillion Viewing Angle: Horizontal 140° Vertical 140°
High Light:

P10 outdoor smd led display

,

P8 led full color outdoor

Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification



Features

3 times aging process.
◆Salty spray test, high voltage test, varying temperature test, waterproof test, vibration test.
◆Long service time and low attenuation by applying dual channels for heat dissipation.
◆High protection grade of IP66 achieved by patented mask design with waterproof and dustproof fuction.

No deformation under sunlight by the use of Anti-UV module mask, Anti-Oxidation module frame with protection from deformation.

Energy Saving Outdoor Fixed LED Display

◆Able to work in all weather outdoor environments. High protection grade of IP65 suitable for winter and cold areas like North European countries and Russia, and high temperature like KSA, Oman, UAE, etc.





Product Description

Parameter
Pixel Pitch(mm)
4
5
6
8
10
Pixel Matrix Per Sq.m
62500
40000
27777
15625
10000
Pixel Configuration
SMD1921
SMD2727
SMD2727
SMD3535
SMD3535
Brightness (nits)
6500
6500
6500
6800
7500
Scan
1/8
1/8
1/4
1/3
1/2
Module Dimension
192x192mm
160x160mm
192x192mm
320x160mm
320x160mm
Cabinet Dimension
960x960mm
960x960mm
960x960mm
960x960mm
960x960mm
Cabinet Resolution
192x192
192x192
160x160
120x120
96x96
Cabinet Weight
44kg / 97Ib
43kg / 95Ib
42kg / 93Ib
41kg / 90Ib
40kg / 88Ib
Power Con. (Max / Avg)
750 / 150 w/sq.m
730 / 130 w/sq.m
700 / 120 w/sq.m
680 / 120 w/sq.m
650 / 110 w/sq.m
Service Access
Front / Rear
Refresh Rate
≥1920 HZ
Grey Scale (bit)
16
Viewing Angle
140(H) / 140(V)
IP Rate
IP65
Input Voltage (AC)
110V / 240V





Cabinet Picture



Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification 0





How to Control



Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification 1



Various Shaped LED Display


Cylinder LED display, Curved LED display, 90 degrees LED display, Round LED display, LED ball.
LEDFUL supply more design and more solutions.





Outdoor Full Color Led Display Advertising Led Billboard P4 P5 P6 P8 P10 with CE ROHS FCC CB Certification 2







Our Service



1)Your inquiry related to our products or price will be replied in 24hrs

2)OEM&ODM,any your customized lightings we can help you to design and put into product

3)Distributoership are offered for your unique design and some our current models

4)Protection of your sales area,ideas of design and all your private information

5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win

Trade Terms



1.Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying



2.Shipping freight are quoted under your requests



3.Shipping port:ShenZhen,Mainland China



4.MOQ:1sqm







FAQ



1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3. 36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates , What's more, we have FCC, SAA, BIS, SASO etc to meet different countries customer's need



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea: 15-20 days; by air: 3-7 days ;by express:3-6days
