Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display

Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display

    • Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display
    • Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display
    • Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display
  • Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display

    Product Details:

    Place of Origin: China
    Brand Name: SCX
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Product Name: P8 Full Color Outdoor Led Screen Module Resolution: 32*16
    Warranty: 5 Years Brightbess: >8000cd/㎡
    Display Function: Video LED Chip: Episatr
    Waterproof Level: IP65
    High Light:

    P8 stadium led screen


    Sport stadium perimeter led display

    P8 SMD Outdoor High Definition Open Front service LED billboards Screen


    PH8 Stadium LED Display

    The stadium LED screen is ideal for places of with huge crowd. Its high resolution picture and wide viewing angle ensure best quality pictures and videos to every corner of the stadium. Stable body protects the display from any damage, even high speed ball.


    High Gray Scale - Better Picture

    The Indoor LED Display is manufactured by using best quality material, purchased from most reputed vendors. The final products feature supreme quality and offers best outputs. High refresh rate and gray scale ensures the picture quality remains seamless.

    Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display 0

    ♦ Product specification

    outdoor  SMD P8
    Resolution/mm 8
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 15625/m²
    Module resolution 32x16
    Module size/mm 256x128MM
    View distance 6-500m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >8000cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Driving mode Constant driving current
    Scanning mode (1/4)
    Frame rate 60Hz
    Refresh frequency


    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Maximum power:/㎡ <800W
    Average power:/㎡ <300W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%


    Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display 1


    ♦ Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing


    Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display 2

    ♦ Packaging and shipping

    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.


    ♦ Our Service:


    Pre-sales support

    1. We offered technical advice to our customers before buying our products.

    2. Help customers to choose suitable products within budget with most economy benefit.

    3. Design the framework structure to install our led products with technical drawing.

    4. We offered software customization for our customer’s specific usage.


    After- sales service

    1. We promise our customers 3 years warranty service!

    2. We provide free maintenance services including remote configuration, technical consultation, and trouble shooting for our customer.

    3. We promise a life time follow up service for all the equipment supply by our company. These include continuously improve of system functions and upgrade of system software.

    4. We offered training to our customer who includes operating and maintenance of our products.


    ♦ Why choose us:

    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.

    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.

    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.

    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to


    After-sales:We will track the products usage and then constantly perfect our products.


    ♦ Our project


    Outdoor Sport Stadium Perimeter P8 Advertising LED Screen Display 3
