Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen
Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen
Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen
Product Details:
Place of Origin: China,shenzhen
Brand Name: SCX
Certification: CB,CE,UL
Model Number: outdoor p3.9
Payment & Shipping Terms:
Minimum Order Quantity: 13 SQM
Price: negotiation
Packaging Details: wooden case,flight case
Delivery Time: 7-16 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 4600 sqm month
Contact Now
Detailed Product Description
Keyword: P3.91 Outdoor Led 500x1000mm Led Screen Pixel Densit: 65536/m2
Module Resolution: 64dots(W)*64dots(H) Brightness: 5500cd/sqm
Specification: Led Video Wall, Outdoor, Full Weather Resistance Warranty: 2~5 Years
High Light:

Backdrop Stage Led Display

,

Weather Resistance Stage Led Display

,

Outdoor P3.91 Led Backdrop Display

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen





P3.91 Outdoor Panel  Features



Pixel pitch 3.91mm

Modules size 250*250mm
500*1000mm cabinet (500*500mm Optional).
High brightness , high refresh rate.
Novastar/HuiDu/Linsn control system *For indoor outdoor
Support Phone,PC,WIFI ,Live etc all signals model input
Specially use for TV studio, conference center,monitoring center and cinema, museum, etc.
Seamless connection, high contrast
ratio, high refresh rate, 16 bit high gray level.

* LED Type: SMD1921
* Pixel pitch: 3.91mm

* Panel size: 500mmx1000mm
* Panel resolution: 128*512pixels
* Brightness: 5,000nits
* Contrast: 3000:1
* Grayscale: 18 bit
* Refresh rate ≥: 3840Hz
* Drive Mode: 1/16 scan, constant current
* Vertical viewing angle: 120°
* Horizontal viewing angle: 140°
* LED density: 65,536LED/sqm
* Dead Pixel Ratio: <0.002
* LED avg life span: 100,000



Electrical
* Power input/output: Outer fast connection IN/OUT
* Power supply: AC 110/230V 50/60Hz
* Max rated current/panel:: AC220V/1.6A
* Working temperature: -20°C/+50°C
* Working humidity: 10~90 RH%

Control
* Control protocol: Novastar/Huidu
* Signal input: IP data Seetronic IN
* Signal output: IP data Seetronic OUT

Mechanics
* Panel size(WxHxD): 500×1000×76mm
* Curvability: mechanics on board, -15° to +15°, can be adjusted by the unit of 2.5°
* IP rating: IP54 (front), IP65 (rear)
* Panel weight: 12kg
* Hanging Panel Quantity ≤: 10
* Compliant Standard: CE, EMC, UL

Advantages

P3.91 Outdoor Leasing LED Screen Panel 500X1000 Die-Cast Adaptive LED Panel Features :
1) Hot Sale 500*1000mm Die-cast aluminum Rental Cabinet. Slim and light weight.
2) Strong Fast Lock, More accurate and easy to handle, make it minimum gaps between cabinet.
3) Light weight, only 14KG for 500x1000mm cabinet.
4) ±15° angle adjustable between cabinet, enable to make into inner arc or outter arc shape even rount shape use 12 cabinet.
5) Fast lock design, good rental hanging solution.

Die Cast aluminum light weight Structure

Outdoor Rental Series is designed to meet the requirements of a wide range of applications. Through thoughtful engineering and craftsmanship, the Outdoor Rental ⅠSeries features a thin, lightweight, high-strength die-casting in a modular design to fit a wide range of simple or complex applications. The unique structural design of Outdoor Rental has pioneered, patented and perfected the use of die-casting in the construction of LED video wall displays.

Seamless screen splicing and Support ±15 degree installation

It has the following advantages: Arc shaped panel edge,seamless splicing and no angle acquirement,perfect arc-bending panel technology vivid visual effects and no distorition.Double-side 15 degree oblique angle design,support ±15 degree assembly,Sticky tape support seamless connection between panels.

Fast, Flexible installation and maintence

From start to finish, the Outdoor RentalⅠSeries accommodates the fast-paced nature of rental, staging and flexible installations.With Outdoor RentalⅠSeries' modular design, free-standing or hanging applications,supporting independent failed module replacement which is quite fast and cost saving for repair and maintence

Outdoor IP65 waterproof protection

The Outdoor RentalⅠSeries designed to perform in outdoor environments. Earning an IP65 Protection Rating, the dust-tight enclosure of the Outdoor RentalⅠSeries works to protect the LED video wall display in outdoor installations.

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 0

P3.91 Outdoor Panel Description

SevenColor-P3.91 is a revolutionary outdoor 3.91 mm LED screen rental panel. Specially designed to allow for large screens to be built quickly and creatively whilst withstanding the rigors of life on the road.
The p3.91is a high-bright, lightweight touring panel designed specifically for life on the road. Its lightweight and
touring chassis design makes it applicable for use both on large-scale indoor and outdoor stages as well as ceilings in TV/Film studios. With optional touring dollies you can reduce your installation time.

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 1

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 2

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 3

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 4

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 5

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 6

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 7

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 8

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 9

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 10

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 11

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 12

Outdoor P3.91 500x1000mm Stage Led Display Elegant Backdrop Screen 13

How to Utlize Led Video Wall

Unique, dynamic outdoor events all have one thing in common: they begin with a great vision. What ways are you using to make sure that your event is compelling, engaging, and unforgettable for those in attendance? LED video screen rental is one of the fastest growing areas in the live production and event industries. Adding personality and dimension to your event has never been easier.

While many people consider LED video wall rentals to be useful in concert and musical event settings, the truth is that LED
displays can be used in a wide variety of live event scenarios. In fact, many companies are turning to rental LED screens for trade show booths, corporate events and meetings, as well as live television broadcasts and tapings.
Rental Series display is a very high quality and affordable solution for your events needs.
Our Outdoor Rental Series is ideal for rental, staging and flexible-fixed applications. Each lightweight display is suitable for
hanging and free-standing installations. Rental ⅠSeries adaptable design enhances installation capabilities. It is available in3.91, 4.81 and 5.95mm pixel pitches.
