Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P7.82-15.628 |
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch(Level): | 15.625mm | Pixel Pitch(Vertical): | 31.25mm |
|---|---|---|---|
| Pixel Composition: | 1R1G1B | Cabinet Size: | 500x1000mm |
| Pixel Resolution: | 4096dots/m2 | Weight: | 25kg/m2 |
| Warranty: | 3 Years | ||
| Highlight: | Window Clear GOB LED Display,Advertising Sign GOB LED Display,Interior LED Advertising Sign |
||
Window Clear GOB LED Display Advertising Sign Screen For Interior
Window clear LED sign advertising display screen for interior
LED Grille screen Features:
1,High Transparent rate,with stretch aluminum stripa design ,good cooling
2,Aluminum cabinet,only16kg /sqm,very light,transport&labor saving.
3,One cabinet ,one cable ,signal &power in one one interface.
4,Double -side IP 67 ,perfectly work in all weather conditions.
5,Front and rear maintenance,10s/unit maintain speed.
6,Dual backup power supply,if one of the power suppy do not work ,another one will keep working.
7,3parts for thr whole screen:cabiner +Frame+Steel Tube,quick andtool-free quickinstallation.
|
Pixel Pitch
|
15.625mm(H*V)
|
|
Pixel Density
|
4096dots/m^2
|
|
LED Shape
|
SMD 3535
|
|
LED Configuration
|
1R1G1B
|
|
Module Size
|
1000mmx500mm
|
|
Driving Mode
|
1/2Scan,constant current
|
|
Cabinet Size
|
customized as the module size
|
|
Cabinet Weight
|
25kg/m^2
|
|
Brightness After Calibration
|
≥7500cd/m2
|
|
Service access
|
Rear
|
|
Contrast
|
1600:1
|
|
View Angle
|
140°(horz.), 140° (vert.)
|
|
Max Power Consumption
|
800 W/sq.m
|
|
Average Power Consumption
|
270 W/sq.m
|
|
Best viewing distance
|
16m-100m
|
|
Gray Scale
|
12-16bits for red,green,blue
|
|
Colors
|
16777216
|
|
Input voltage (AC)
|
110V ~ 240V
|
|
Frame Frequency
|
50Hz-75Hz
|
|
Refresh Rate
|
≥600Hz
|
|
Brightness Adjustment
|
0-100%
|
|
Gamma Correction
|
( -0.5 -- 5.0 )
|
|
Color Temperature
|
6500-9000K
|
|
Operation System
|
Win7&XP
|
|
Control Mode
|
Synchronization with PC
|
|
Stock Temperature
|
(-40℃~+85℃)
|
|
Operating Temperature
|
( -30℃~+50℃ )
|
|
Operating Humidity
|
10-90% RH
|
|
Life Span
|
100,000Hours
|
|
MTBF
|
≥10,000Hours
|
|
IP Rating(Front/Rear)
|
IP65
|
|
Flatness of the screen
|
1mm max
|
|
Control Distance
|
UTP CAT5E:100m,Multi-Mode Fiber:500m,Single-Mode Fiber:15km
|
Packing:
Company profile
Shenzhen SCXK Electronic Co.,Ltd has the standard new factory, and about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display, led wireless car used screen, transparent screen, poster screen etc. It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality, good price product market to price product market to provide perfect product and service for our customers.
Certificate
Packaging and shipping
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Our service
Warranty
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!
Installation
1.We can assist the training and technical support for the customer in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need
