Nationstar P3.91 Curve Led Screen For Live Show Tv Studio Stream

Product Details:

Place of Origin:	China，shenzhen
Brand Name:	SCX
Certification:	CB,CE,UL
Model Number:	outdoor p3.9

Payment & Shipping Terms:

Minimum Order Quantity:	16 sqm
Price:	negotiation
Packaging Details:	wooden case，flight case
Delivery Time:	7-16 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	4300 sqm month

Contact Now

Detailed Product Description

Specification:	Video Wall	Cabinet Resolution:	128 Dot * 256 Dot, 128*128 Dot
Cabinet Size:	500x500mm Or 500*1000mm	IP Protective Index::	IP65
Product Keywords::	P3.91 Led Video Wall Panel	Fresh Frequency::	3840hz
High Light:	Nationstar Curve Led Screen , Live Show Curve Led Screen , Nationstar P3.91 Led Display Screen

P3.91 Outdoor Video Wall Led wall Stage Rental LED Display Screen HUB cabinet for Concert

Features

Standard dimension module size 250mm×250mm,cabine size 500mm×500mm,Compatible model P3.91 and other pixel Pitch standard size cabinet design.

High-precision die-cast aluminum cabinet, seamless unit box,Perfect solution for both outdoor using

Light and strong cabinet design with quick locate handle lock canbe quickly and easily assembled in various ways, it can be used in a variety of occasions ,to meet different customer requirement for a variety of applications.

140-degree viewing angle assure the screen has wider view area, meet various rent environment and requirements.

Sophisticated materials for led lamp and IC, uniform screen, real andnatural color, high grey scale, high refresh rate to ensure the amazing photographic effects.

Specification

Pixel Pitch	3.91
Physical Density	65410
LED Configuration	1RGB
LED type	SMD1921
Module Size	250×250
Module Resolution	64x64
Module Power Consumption	750W
Driving Mode	Constant Current Drive
Scanning Mode	1/16
Horizontal Viewing Angle	140
Vertical Viewing Angle	140
Brightness	≥800
Grey Scale	16bit
Refresh Rate	≥3480
Cabinet Resolution	128x128
Cabinet Max Consumption	200
Cabinet Average Power Consumption	80
Cabinet Size	500×500
Cabinet Weight	7.85
Cabinet Thickness	85
Cabinet Material	Die-casting Aluminum
Color	>16.7
Input Voltage	AC 110V~220V +/-10%
Refresh Frame Frequency	50-60
Protection Level	IP65
Working Environment	outdoor
Working Temperature	-40° -+65°
Storage Humidity Range	10%~90%
Life Span	100,000 hours

Product Paramenters

Packing & Delivery

Certifications

FAQ

Why so many clients choose TOPLED?

Our led display has applied many countries in the world. Many countries have our projects.

TOPLED's led display unique advantage

-------service

>Our engineer will be on your service. We can give you technology support at any time.

We will be tracking your orders, from the pre-sale to the after-sale and also serve you in this process.

--------price

Our price is based on the quantity, We have the basic price for one square meter. For each additional 5 square meter will have a discount when beyond 10 square meter. What is more, free power and fan will send to you. The cabinet will be free.

--------Quality

Quality is our reputation, we have eight steps for our quality inspection, From material to the finished goods. Quality is what we pursuit.

Choose TOPLED, you choose the cost-effective , high quality and good service.
