Name: Outdoor P3.91 Advertising LED Screen with High Brightness, Waterproof IP65, and Full Color Display
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P3.91
Price: 10000 USD
Availability: InStock

Home Products Advertising LED Screens

Outdoor P3.91 Advertising LED Screen with High Brightness, Waterproof IP65, and Full Color Display

Product Details:

Place of Origin:	China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/SGS
Model Number:	P3.91

Payment & Shipping Terms:

Minimum Order Quantity:	negotiation
Price:	negotiation
Packaging Details:	Packed in wooden case and flight case for outer packing
Delivery Time:	10 working days after received your payment
Payment Terms:	T/T or western Union
Supply Ability:	5,000/ Sq m per month

Contact Now

Detailed Product Description

Module Size:	250mm*250mm	Pixel Pitch:	3.91mm
Resolution:	64dots*64dots	Brightness:	>2500cd/sqm
Viewing Angle:	110°(Horizontal),50°(Vertical)	Power Consumption:	600 W/sq.m (Max), 300 W/sq.m (Avg)
Highlight:	outdoor advertising led display , advertising led billboard

Outdoor P3.91 Advertising LED Screen Rental, Digital Advertising Display Screens SCXK

High Resolution Outdoor P3.91 Advertising LED Screen, Digital Advertising Display Screens

Shenzhen Shichuangxinke Electronics Co., Ltd started in 2005, Shenzhen China, has been focusing on the international market to realize the global strategic layout. With the perfect global marketing network, our products are sold to The Middle East, South America, North America, Europe, Southeast Asia, Australia, Africa and other regions.

Relying on the strong technical strength, the advanced production management system, the complete operating programs and our international business team, we successfully set up a base gathering the abilities of R & D, production and sales in Shenzhen.

Product Specifications

Product Name	High resolution outdoor P3.91 advertising LED screen rental use, with 1/16 scanning 250mm*250mm
Service	Your inquiry will be replied within 12 hours
Brand	SCX
Material	Stainless, aluminum, steel, epoxide resin, PE
Item	Indoor P2.5, P3, P4, P5, P6, P7.62 Outdoor P6, P8, P10, P12, P16, P20
Feature	High brightness, good resolution, working stable, easy installation
Grade	IP43-IP65
Driving mode	Constant driving current
Stock	Regular items of LED display have stocks
Color temperature	6500-9500K
Packing Method	Flight case & Plywood case or Customized Packing
Power supply request	AC85-264V (50HZ-60HZ)
Payment Term	T/T, Western Union
Delivery Time	Within 7-30 days according to your required size & quantity
Using Range	Shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and etc.

Technical Specifications

Specification	Details
LED Lamps Type	SMD2121 (High Brightness LEDs)
LED Standard	Real Pixel (1R1G1B)
Red Wavelength	625-630nm
Green Wavelength	515-530nm
Blue Wavelength	465-475nm
LED Module Pixel Pitch	3.91mm
Module Size	250mm x 250mm
Module Resolution	64 x 64 dots
LED Cabinet Size	500mm x 500mm
Cabinet Resolution	128 pixels x 128 pixels
Cabinets Material	Iron steel cabinet
Pixel Density	65410 pixels/sq.m
Drive IC	MBI5024
Power Supply	Series connection
Brightness	>2500cd/sqm
Display Color	16.7 million
Viewing Angle	110° (Horizontal), 50° (Vertical)
Best Viewing Distance	1m ~ 150m
Max Power Consumption	600 w/sq.m
Average Power Consumption	300 w/sq.m
Weight	35Kgs/sq.m
Refresh Rate	3000hz
Input Voltage	AC220V/50H or AC110V/60H
Output Voltage	DC5V, 40A
Grey Scale Levels	1024
Display Colors	R(1024) x G(1024) x B(1024)
MTBF	10,000 hours
Life-span	100,000 hours
Protection Level	IP45
Failure percentage of LEDs	less than 0.0003
Working Temperature	-25℃ ~ 65℃
Drive Mode	1/8 scanning
Working Humidity	10% ~ 99%
Control Method	Synchronization & Asynchronization
Control System	LINSN Control System (sender, receiver, HUB with 75 interface, software)
Software	LED Studio (LINSN)
Input Signal	MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC etc.
PC Operating system	Windows & Vista

Our Service

1) Training after order: After the order is placed, professional training will be offered, including software use, operate safety, maintain equipment

2) Installation and debugging: BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual

3) Warranty: 2 years warranty, lifetime maintenance. Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates

4) Maintenance: Maintenance principles: response in time, solve problems asap and ensure the use. Maintenance period: In the maintenance period of the LED display body, free of all maintenance charges. After maintenance period, only charge the material cost and labor cost

Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine, Automatic Glue-pouring Machine, Solder Paste Printing Machine, Reflow Soldering Machine, Automatic Solder Paste Printing Machine, Withstand Voltage Tester, Ground Resistance Tester, Medium-speed Automatic SMT Machine, Super Mute Terminal Machine, Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.

Competitive Advantages

2 years' warranty with free repair service
24/7 Hours online Remote Support
Solution and PCB design
Free factory training
On site installation instruction and regular inspection
Small order accepted
