Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | shenzhen,China |
| Brand Name: | SCX |
| Certification: | CE,CB,IEICC,FC |
| Model Number: | indoor p2.5 |
| Minimum Order Quantity: | 19 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case，flight case |
| Delivery Time: | 5-7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 3200 sqm per sqm |
| Brightness: | 1000cd/㎡ | Color Depth: | 16bit |
|---|---|---|---|
| Contrast Ratio: | 4000:1 | Input Voltage: | AC110V/220V |
| Lifespan: | 100,000 Hrs | Operating Temperature: | -20℃~50℃ |
| Pixel Pitch: | 2.5mm | Refresh Rate: | 1920Hz |
| High Light: | 2.5mm indoor full color led display,church indoor full color led display,2.5mm indoor full color led screen |
||
HD 160000dots/sqm,high brightness
Ultra thin and ultra light
Low attenuation,high gray level,good stability,anti-static
Entire die casting aluminum cabinet 480*480mm OR 640*640mm
| P2.5 indoor full color led display | ||
| Unit Module | Item | Parameter |
| Part No | P2.5-LC-32S | |
| Pixel pitch | 2.5mm | |
| Module size | 160mm*160mm | |
| Tube chip color | full color | |
| Pixel Density | 160000 dots/square meter | |
| led type | SMD2121 | |
| led combination | 1R1G1B | |
| Module resolution | 64*64dots | |
| main technical parameters |
Scan method | 1/32s |
| refresh rate | ≥1920HZ-3840HZ | |
| Brightness of white balance | ≥800-1000cd/square meter | |
| cabinet resolution | 192mm*192mm | |
| cabinet size | 480mm*480mm/640mm*640mm | |
| Best view distance | 2.5m-50m | |
| Best view angle | 160degree(W)*160degree(H) | |
| Storage temperature | -35℃-+85℃ | |
| Working temperature | -20℃-+50℃ | |
| working voltage | AC110/220V±10% | |
| Average power consumption | <600W/square meter | |
| Max power consumption | <1200W/square meter | |
| brightness adjustment method | Brightness induction automatic adjustment |
|
| MTBF | ≥5000hrs | |
| Control system |
Display card | DVI graphics |
| Control method | Synchronization | |
| Operation syetem | WIN98,WINXP,WIN2000,etc | |
| display sign | RF,S-Video,RGB,RGBHV,YUV, YC,COMPOSITION, etc |
|
SCX has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
