P6 stage SMD Full Color Indoor Rental LED Display Screen 6000cd/M2

Brand Name:	SCXK
Model Number:	P6
MOQ:	2 sqm
Price:	negotiation
Payment Terms:	Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL

Pixels:

6mm

Tube Chip Color:

Full Color

Voltage:

DC5V

Refresh Rate:

>=180HZ

Maximum Power:

600m2

Module Size:

192mmx192mm

Brightness:

6000cd/m2

Certificates:

CE,RoHs,FCC,ISO

Dot Density:

27778

Driving Mode:

1/8 Scan

IC:

MBI 5024 IC

Chip Brand:

Epistar Led

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

P6 Rental LED Display Screen

Shopping Mall Rental LED Display Screen

Indoor Rental LED Display Screen

Product Description

P6 SMD Full Color Indoor Rental LED Display Screen

Product Specifications

Attribute	Value
Pixels	6mm
Tube Chip Color	Full color
Voltage	DC5V
Refresh Rate	≥180HZ
Maximum power	600m²
Module size	192mm × 192mm
Brightness	6000cd/m²
Certificates	CE, RoHs, FCC, ISO
Dot density	27778
Driving mode	1/8 scan
IC	MBI 5024 IC
Chip brand	Epistar led

Product Features

High-Quality Visual Experience

Our customized full-color LED video board delivers ultra-high brightness that remains clearly visible even under direct sunlight. The display features exceptional color uniformity and delicate image rendering. Curved splicing capability allows seamless integration with any environment, creating maximum visual impact for outdoor applications.

Advanced Weather Protection

The unique waterproof casing with independent drainage holes and high-grade sealant ensures reliable operation in all weather conditions. Features include:

High waterproof rating for outdoor durability
UV-resistant materials prevent fading
Anti-deformation module kit maintains structural integrity

Seamless Display Technology

The LED screen can be seamlessly stitched in any direction, size, or shape. Unlike rear projection or LCD splicing, our technology eliminates brightness variations and black seams between cells, delivering perfect visual uniformity with no separation lines or missing information.

Technical Specifications

Model Number	HX-P6-8s	Best Viewing Distance	6M-50M
Model Size	192MM × 192MM	Pixel Resolution	160°(W) 120°(H)
Pixels Density	27777dots/㎡	Temperature	Storage: -35℃/+85℃
Pixel Pitch	6mm	Operation Humidity	10%-75%
Package Mode	SMD3535/2727	Working Voltage	AC220V±10%
Pixel Resolution	32Dots(W) × 32Dots(H)	Average Power Consumption	≤320W/m² ≤370W/m²
Module Thickness	14.85MM (Non magnetic column)	Max Power Consumption	≤750W/m² ≤900W/m²
Model Weight	0.45kg	Control Method	Synchronization

Quality Assurance

CE, FCC, RoHS, C-Tick certified
High brightness: >6000nits with high refresh rate
Superior uniformity for excellent display effect
2-year warranty with comprehensive after-sales service
Supports video, flash, animation, graphics, and text
Free installation structure drawings provided
OEM services available

Frequently Asked Questions

What is the payment method?

We support various payment methods, with TT (Telegraphic Transfer) being the most common. 30% deposit before production, 70% balance before delivery.

What's the pixel pitch for Outdoor LED Display Screen?

Outdoor models available in P6mm, P8mm, and P10mm configurations.

Where is it used for?

Ideal for outdoor & rental applications including stage backdrops, live events, concerts, and exhibitions.

What's the controlling system?

Standard system is Novastar, with optional support for Linsn and other control systems.

Note: Specifications can be adjusted according to client requirements. Contact us for customized solutions.
