Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China(Mianland) |
| Brand Name: | SCXK |
| Certification: | CE,RoHS,FCC,CCC,SAA,TUV,UL |
| Model Number: | SCXK-P2.5 |
| Minimum Order Quantity: | Negotiations |
|---|---|
| Price: | Negotiations |
| Packaging Details: | Wooden and flight cases,it's up to you. |
| Delivery Time: | 7-10 working days after payment |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 5000sqs/month |
| Brand Name: | RGB LED Display | Brightness: | ≥1200cd/sq |
|---|---|---|---|
| Certifications: | CE,RoHS,FCC,CCC,SAA,TUV,UL | LED Chip: | Epistar |
| Waterproof: | IP34 | Operation Power: | 220V 60HZ |
| Module Size: | 160*160mm | Cabinet Size: | 480*480mm |
| Control System: | LSN | Pixel Density: | 160000dots/sq |
| Resolution: | 64*64 | Scan Mode: | 1/32 |
| LED Type: | SMD2121 | Indoor Options: | P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10... |
Indoor Full Color LED Display P2.5 Rental High Resolution 1/32 Scan 160*160mm Module
Specifications :
| Indoor P2.5 LED Display | |||||
| Resolution/mm | 2.5 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 160000/square meter | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 160x160 | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1200cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
1. Reply to your inquiry within 24 hours.
2. Provide free solutions, free technical support and free training.
3. Deliver with the lowest cost and fastest shipping method
4. OEM and ODM, any customized lamps we can help you design and put into products
5. Provide special discounts and sales area protection for our dealers.
6. If necessary, you are warmly welcome to visit our company.
FAQ
1.How long your company has been in this business?
More than 10 years manufacturing experience on LED displays, professional workmanship & design.
2. What is your lead time?
Under the normal condition, sample order for 3-7 working days, regarding mass order, if we have available raw material,the lead time will around 15 working days, otherwise, would be 20-30 working days
3. What is your payment method?
Our usually practice for payment is by T/T for the mass order and also we do the trade assurance ( Provided by Alibaba and Gteak to make sure your payment, shipment, goods’ quality security and ensurance)
4. What is your shipping and packing way?
Our standard packing for modules are carton box and for the led cabinet, we do wood box or flight case as per customers’ requests. For the mass order ( fit for a container), we do shipment by Sea and for others usually by express or airlin
Delivery and Shipping
Wooden boxes and flight cases are available.
Shipping by sea,air or DHL,multible ways for your choices.
