Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P4.81 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD1200-1400per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 4.81 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/13 Scanning | Module Size: | 250x250 |
| Cabinet Size: | 500x500mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Warranty: | 3-5 Years |
| Brightness: | 1000/6000 | Control System: | LSN |
| Highlight: | P4.81 Rental LED Display,Rental LED Display P5,Rental LED Display Die-Cast Aluminum |
||
P4.81 1R1G1B Rental Led Display P4 P5 HD Indoor and Outdoor
Products Features:
1. Equipped with intelligent lighting equipment, adaptive environmental adjustment, not affected by ambient light, strong display effect, rental LED display screen is environmentally friendly and energy-saving.
2. It can be spliced in any direction, any size, and any shape to present a perfect seamless visual effect.
3. The rental LED display screen adopts die-cast aluminum frame design, the screen is ultra-light and thin, saving space and cost, and stylish and beautiful. The die-cast aluminum material has better heat dissipation performance and extends the service life of the display screen.
P4.81 Ultra thin LED display
2)Transmission: WIFI ,USB BLUETOOTH ;
3)Display languages: World language,such as English, Simplified Chinese, Traditional Chinese, Korean,
Japanese, Russian, and all European countries language;
4)Display ability:10 messages for text or picture,english 6000 chars or chinese 3000 chars.
5)Brightness: 4 different levels,25%,50%,75%,100%；
6)Speed: 8 different levels by pc software ；
7)Function:Program the customers own message easily through the led badge software by pc；
8)Key switch: brightness key for 25%,50%,75%,100% ;message key for 1-8 messages.
9)Input voltage: 5V or 12V or 90-260Vac;
10)Standard accessories: CD, USB data line, Power supply.Iron chain.
11)Optional accessories:a-12V for car used and add suckers ;b-L shaped bracket.
Factory Introduction:
SCX Co.,Ltd is a professional manufacturer of LED display specializing in indoor,outdoor,rental LED display screen according to clients' need and real application.we focus on LED technology only with the principle of "low cost control,high quality output and customer first.
Specifications :
| outdoor SMD P4.81 | |||||
| Resolution/mm | 4.81 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/m² | ||||
| Module resolution | 52z52 | ||||
| Module size/mm | 250x250mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/13 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
FAQ
Q1: What can you buy from us?
A: Rental LED Display, Outdoor LED Display, Indoor LED Display, Transparent LED Screen, Floor Tile Screen, Creative Design LED Screen and Etc.
Q2: Can I customize it?
A: Of course. All the goods can be customized, we have a professional product development team, welcome to customize.
Q3: What is Price per square meter of screen?
A: Welcome to send us inquiry. Our professional sales engineers will provide suitable solutions.
Q4: What is the warranty?
A: 5-8 years Warranty.
Q5: How many days for producing?
A: 1-3 days for inventory products and 10-15 days for customized products.
Q6: How to operate and use it?
A: It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance and remote assistance.
