P2 Indoor Full Color SMD LED Display Screen 2mm Pixel For Wedding Halls

Brand Name:	SCXK
Model Number:	P2
MOQ:	5 pcs
Price:	negotiation
Payment Terms:	Western Union,MoneyGram,T/T
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL/CB

Pixels:

2mm

Display Function:

Video

Waterproof:

Ip43

Cabinet:

Die-catsing Aluminum/iron

MBI:

5124

Viewing Angle:

H:100 V:50

Voltage:

DC5V

LED Parameter:

R:625-630nm

Module Size:

320*160mm

Cabinet Size:

640*640/960*960mm

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

P2 indoor LED screen

indoor stage LED display screen

indoor wedding halls LED screen

Product Description

Indoor Fine Pitch Ultra Thin SMD P2 Full Color LED Display Screen for Stage Wedding Halls

Product Specifications

Pixels	2mm
Display Function	Video
Waterproof	IP43
Cabinet	Die-casting aluminum/iron
MBI	5124
Viewing Angle	H:100° V:50°
Voltage	DC5V
LED Parameter	R:625-630nm
Module Size	320×160mm
Cabinet Size	640×640/960×960mm

Detailed Technical Specifications

Lamp size	1515
Resolution/mm	2
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	250000/m²
Module resolution	160×80
Module size/mm	320×160
View distance	≥2m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>1000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120°
Vertical view angle	60°
Signal Process bit	10 or 14 bit
Grey process	1024×1024×1024 16834×16834×16834 65536×65536×65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/40
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating: -20-45℃ Storing: -25-55℃
Maximum power:/㎡	<1000W
Average power:/㎡	<300W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor (need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators (need customization)
Software environment	WindowsNT, Windows1999, WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof, dustproof, high temperature protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Humidity(working)	10-95%
Humidity(storing)	10-95%

Key Advantages

Natural Heat Dissipation (no cooling system needed)
360 degree rotation capability
Stunning Visual Experience
High recall rate and attracting customers

Product Description

This ultra-thin SMD P2 LED display is specially designed for indoor applications in wedding halls, stages, and similar venues. Featuring a 360° viewing angle, it delivers a perfect viewing experience from any position.

The front service design makes maintenance easy when needed. The modular construction allows for flexible configurations to meet various project requirements.

Packaging and Shipping

Available in wooden case or flight case packaging. Multiple shipping options including sea, air, or DHL express.

Why Choose Our LED Displays

Continuous Quality: With over 10 years of LED display manufacturing experience, we maintain strict quality control through standardized modular production.

Competitive Pricing: Our large-scale production capacity and efficient manufacturing processes allow us to offer high-quality products at competitive prices.

Fast Delivery: We honor our delivery commitments and implement emergency procedures when needed to ensure timely product supply.

Perfect Service: From pre-sales consultation to after-sales support, we provide comprehensive service to ensure customer satisfaction.
