Curve P3.91 advertising led screen large high definition led video wall

Curve P3.91 advertising led screen large high definition led video wall

Curve P3.91 advertising led screen large high definition led video wall
Curve P3.91 advertising led screen large high definition led video wall
Curve P3.91 advertising led screen large high definition led video wall
Product Details:
Place of Origin: Shenzhen
Brand Name: SCX
Certification: CE/ROHS/FCC/CB/IECEE
Model Number: P3.91
Payment & Shipping Terms:
Minimum Order Quantity: 5 Square Meter/Square Meters
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Module Size: 250mm*250mm LED Brand: Epistar/Cree
Model Number: P3.91 View Distance: 10--200m
Module Pixel(dots)way: 16*8 Driving Method: 1/8 Scan
Pixel Density: 65410dots/m2 Cabinet Size(WXH): 500x500mm
Number Of Colors: 16.7 Trillion Color Temperature Condition: 3500K~9500K,(can Be Adjustable)
High Light:

led stage display

,

stage background led screen

Curve Led Screen Features

1. high brightness DIP LED display are used for outdoor led display, keeps the display contant visible even if facing the strong sunshine directly
2. High color uniformity and clear image can bring you a vivid audio visual effect
3. with high fresh rate controller,guarantee that no scan line when taking photos
4. Used for meeting room,lobby of hotel ,cinema,shopping mall and station,airport, studio,stadium and studio.



Curve Led Screen Functions

1) High intensity and can be adjusted, so can meet the request of the customers according the application environment;
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;
3) To pictures and character, have clear, exquisite and real display effect;
4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion;
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.




Curve Led Screen Technical Specification

Model
P2.5
P2.98
P3.91
P4.81
LED Type
SMD1415
SMD1415
SMD1921
SMD1921
Physical Density(Dot/sqm)
147456
112896
65536
43264
Module Resolution
96x96
84x84
64x64
52x52
Module Size(WxH/mm)
250x250
250x250
250x250
250x250
Panel Dimension (WxHxD/mm)
500x500x83
500x500(1000)x83
500x500(1000)x83
500x500(1000)x83
Panel Resolution
192x192
168x168/168x336
128x128/128x256
104x104/104x208
Module Qty per Cabinet(WxH)
2x2
2x2/2x4
2x2/2x4
2x2/2x4
Panel Weight (kg/panel)
8.5
8.5/13.5
8.5/13.5
8.5/13.5
Maintenance Mode
Front Maintenance
Front Maintenance
Front Maintenance
Front Maintenance
Cabinet Frame
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Brightness(Nits)
≥3500
≥3500
≥3500
≥3500
Color Temperature (K)
1000-18500 Optional
1000-18500 Optional
1000-18500 Optional
1000-18500 Optional
Viewing Angle(H/v)
160°/160°
160°/160°
160°/160°
160°/160°
Refresh rate
≥3840 Hz
≥3840 Hz
≥3840 Hz

Grey Level
16 bit
16 bit
16 bit
16 bit
The optimal viewing distance
3-50m
4-150m
4-150m
4-150m
Display color
68.7billion
68.7billion
68.7billion
68.7billion
Contrast Ratio
5000:1
5000:1
5000:1
5000:1
Frame Frequency(Hz)
50/60
50/60
50/60
50/60
Drive Mode
1/32scan
1/28scan
1/16scan
1/13scan
Protection Degree
IP65
IP65
IP65
IP65
Max Power Consumption(W/sqm)
800
800
800
800
Avg Power Consumption (W/sqm)
200-300
200-300
200-300
200-300
Power Requirement
AC90-264V,47-63Hz
AC90-264V,47-63Hz
AC90-264V,47-63Hz
AC90-264V,47-63Hz
Working Temperature
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
Storage Temperature
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%


Curve Led Cabinet
Curve P3.91 advertising led screen large high definition led video wall 0

Curve P3.91 advertising led screen large high definition led video wall 1

Curve P3.91 advertising led screen large high definition led video wall 2

Curve P3.91 advertising led screen large high definition led video wall 3

Curve P3.91 advertising led screen large high definition led video wall 4





Why choose us

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.
