Home ProductsIndoor Full Color LED Display

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel
indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel
indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel
Product Details:
Place of Origin: Shenzhen in China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL/CB/IECEE
Model Number: P3
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Module Size: 192*192mm Module Resolution: 64*64
Pixel Density: 111111 Dots/sqm Driving Method: 1/32scanning
Contrast Ratio: ≥6000:1 Color Temperature Condition: 3500K-9500K,(can Be Adjustable)
Number Of Colors: 16.7 Trillion Brightness Adjustment: 0-100% 8 Levels
High Light:

led full color screen

,

indoor led display screen

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel



Indoor Full Color Led Display Features



1.Standard dimension module size 250mm×250mm,cabine size 500mm×500mm,Compatible model PH3.91/PH4.81/PH5.95 and other pixel Pitch standard size cabinet design.
2.High-precision die-cast aluminum cabinet, seamless unit box,Perfect solution for both outdoor using
3.Light and strong cabinet design with quick locate handle lock canbe quickly and easily assembled in various ways, it can be used in a variety of occasions ,to meet different customer requirement for a variety of applications.
4.140-degree viewing angle assure the screen has wider view area, meet various rent environment and requirements.
5.Sophisticated materials for led lamp and IC, uniform screen, real andnatural color, high grey scale, high refresh rate to ensure the amazing photographic effects.





Indoor Full Color Led Display Product Specification



Model
P2
P2.5
P3
P3.91
LED Type
SMD1515
SMD1515
SMD2121
SMD2121
Physical Density(Dot/sqm)
250000dots/m2
160000
111111
65536
Module Resolution
128dots×64dots
100x100
64dots×64dots
64x64
Module Size(WxH/mm)
256mm × 128mm
250x250
192mm × 192mm
250x250
Panel Dimension (WxHxD/mm)
512mmx512mm
500x500x83
576x576 x83
500x500(1000)x83
Panel Resolution
256dotsx256dots
200x200
192x192
128x128/128x256
Module Qty per Cabinet(WxH)
2x4
2x2
3x3
2x2/2x4
Panel Weight (kg/panel)
7.5
7.8
7.5/12.5
Maintenance Mode
Front Maintenance
Front Maintenance
Front Maintenance
Front Maintenance
Cabinet Frame
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Brightness(Nits)
≥1000
≥1000
≥1000
≥1000
Color Temperature (K)
1000-18500 Optional
1000-18500 Optional
1000-18500 Optional
1000-18500 Optional





Viewing Angle(H/v)
160°/160°
160°/160°
160°/160°
160°/160°
Refresh rate
≥3840 Hz
≥3840 Hz
≥3840 Hz
≥3840 Hz
Grey Level
16 bit
16 bit
16 bit
16 bit
The optimal viewing distance
2.5-50m
4-100m
4-100m
4-100m
Display color
68.7billion
68.7billion
68.7billion
68.7billion
Contrast Ratio
8000:1
7000:1
6000:1
5000:1
Frame Frequency(Hz)
50/60
50/60
50/60
50/60
Drive Mode
1/32scan
1/32scan
1/32scan
1/16scan
Protection Degree
IP34
IP34
IP34
IP34
Max Power Consumption(W/sqm)
600
600
600
600
Avg Power Consumption (W/sqm)
200-300
200-300
200-300
200-300
Power Requirement
AC90-264V,47-63Hz
AC90-264V,47-63Hz
AC90-264V,47-63Hz
AC90-264V,47-63Hz
Working Temperature
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
Storage Temperature
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%
-20~60°/10%~85%



Indoor Full Color Led Display Project

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel 0





Indoor Full Color Led Display Production process



1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel 1



Indoor Full Color Led Display Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.



indoor full color P1.875 P2 P2.5 rental stage background hd big media tv led display screen led video wall panel 2



Our advantages



Professional Manufacturer of led display

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 6-8 working days

8. Excellent R&D team,factory Price and assure you quality goods.





FAQ



1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.

2. What kind of display do we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display for you choose.

3. What about the lead time for an order?
Always: 10-17 days, as your order quantity, sometimes we have stock, can delivery within 7 days.

4. What about the warranty?
We have Three years quality guaranteed, spare parts such as led module, receiving card, control card, power supply are damaged not cause of artificial damaged, then it's free maintenance and ship back new ones for replacement.

5.How about the quality?
Our led products must be testing of at least 72hours before shipping, from purchase raw materials to ship ,Each step has strict quality control systems to ensure led display with good quality.

6. Can you offer a technical support? Since it's my first time....
We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to done if you are really don't know how to control(Our Engineer can text English, we can saving more time )
We're devoted to innovative high-end led display with over 15 years manufacturing experience, and we believe you could get a professional solution and best service from REISS. We're happy to serve you.
If you need led display screen,welcome to contact us,we can customize according to your needs.
For more questions about ShiXin Display Technology wholesale price full color smd outdoor/indoor led video display screen fixed with iron cabinet , please contact me of ShiXin Display Technology direct OEM manufacturer right now! Welcome any question!
