Shenzhen Shichuangxinke Electronics Co.,Ltd

professional makes good quality, provide perfect product and service  for every customer.

Home ProductsGOB LED Display

Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD

Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD

  • Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD
  • Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD
  • Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD
Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD
Product Details:
Place of Origin: SHENZHEN
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P2.5
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Module Size: 320*160mm Pixel Density: 160000
Pixel Composition: 1R1G1B Module Resolution: 128*64
The Optimum Viewing Angle: H:120° V:120° Life Span: 100000 Hours
Working/ Storage Humidity: 10%~90% RH Refresh Rate: ≥180Hz
White Balance Luminance(CDm2): ≥1000CD/m2 Ave.consumption(w/sqm): 650
Input Signal: AV, S-VIDEO, VGA, DVI, HDMI, SDI, DP
High Light:

rental led display screen

,

led rental screen

Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD





Production process

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing











Specifications



Item P2.5
Pixel pitch 2.5 mm
Pixel density(dots/sqm) 160000/sqm
LED encapsulation SMD2121
Driving method 1/30
Module size(mm) 320*160
Resolution of module 128*64
Cabinet size(mm) 640*640
Max. consumption(w/sqm) 1200
Ave.consumption(w/sqm) 650
Brightness >1000cd/ sqm
Refresh rate >600HZ
Color temperature 6500K
View angle(H/V) 160°/140°
Grey scale 16bit
Brightness adjustment 256 grade/ Manually/ Automatically
Working/ storage tempereture -20℃~50℃/ -30℃~60℃
Working/ storage humidity 10%~90% RH
Working voltage AC220/110V 50Hz
Protect degree IP43
MTBF >5000h
Life span 100000h
Input Signal AV, S-VIDEO, VGA, DVI, HDMI, SDI, DP
Operation system Windows 7/XP
Control distance cat-5 data cable:<100m, optical fiber<15km











Advantages of  GOB Led display



(1) Waterproof, dump-proof, dust-proof, anti-collision

(2)  With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

(3)  Weatherproof design, completely outdoor use.

(4)  Easy for assembling and connection with the connector added.

(5)  High color uniformity and clear image can bring you a vivid audio visual effect.

(6) Both front and rear access are available.

(7) The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.

(8)  Use the same level of red, green and blue led chips, which makes the image display of whole led display more excellent and uniform.

(9)  The maintenance of pixel and single led has been realized.

(10)  Good quality raw material, accurate technique and careful inspection insures the high quality of led display





Affordable Price GOB COB HD High Resolution Indoor Full Color LED Display over 1000CD 0











FAQ



Q1. How could I buy the products I need if there is no price in the website?

You can send your inquiry to us about the products you need,our sales will reply you within 24 hours to help you make the order.


Q2. How long could I get reply of my inquiry?

You will get a reply within 24 hours.



Q3. What kind of warranty do you offer?

 all product here we offer 3 year at least warranty.



Q4. How is the after sales service?

We have a professional team which is in charge of after-sales service, also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems.



Q5. What kind of payment methods do you have As a manufacturer?

We take T/T  and Cash as payment terms


Q6. How long will it take to deliver goods?

We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.



Q7. What kind of packaging you offer?
During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
