2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen

2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen

    • 2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen
    • 2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen
    • 2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen
  • 2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen

    Product Details:

    Place of Origin: Shenzhen
    Brand Name: SCX
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: SCXK- P1.56

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Module Size: 200mm*150mm Module Resolution: 128*96
    LED Encapsulation: 1R1G1B Pixel Density: 410914 Dots/sqm
    Cabinet Size: 400*300mm Pixel Pitch: 1.56mm
    LED Size: SMD 1010 Driving Mode: Static Full Color
    Brightness: 10000cd Contrast: ≥6000:1
    Display Color: 1.07 Billion Brightness Adjustment: 0-100% 8 Levels
    Operation Power: 220V 60HZ Working Voltage: DC5V
    Max Power Consumption: 750 W Average Power Consumption: 280 W
    Frame Update Frequency: 100hz Screen Refresh Frequency: 480hz
    Gamma Correction: (-0.5—5.0) Operating Temp.: - 10° —+55° Celcius Degree
    Operating Humidity: 10 - 90 % RH Operating Life: 100,000 Hours
    MTBF: 5000 Hours
    High Light:

    rental led display screen

    ,

    led rental screen

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen





    1. Lightweight. Convenient in transporting and installing and saving labor cost, suitable for flow shows.
    2. Nice appearance and simple structures.
    3. Jointed correctly, being installed and dismounted by one person without tool.
    4. Humanized operating interface with breakdown indicator lights, easy to maintain.
    5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



    ♦ Specifications

    1  smd 1010 led display
    2 Supper refresh rate
    3 Supper energy saving system
    4 High brightness



    Part No. P1.56
    Module Size 200*150mm
    Module Resolution 128*96
    LED Encapsulation 1R1G1B
    Pixel Density 410914dots/sqm
    Cabinet Size 400*300mm
    Pixel Pitch 1.56mm
    LED Size SMD 1010
    Driving Mode Static Full Color
    Brightness 10000cd
    Contrast ≥6000:1
    Display Color 1.07 billion
    View Angle 120° degree Horizontal & 60° degree Vertical110
    Brightness Adjustment 0-100% 8 levels
    Operation Power 220V 60HZ
    Max Power Consumption 750 w
    Average Power Consumption 280 w
    Frame Update Frequency 100hz
    Screen Refresh Frequency 480hz
    Gamma Correction (-0.5—5.0)
    Operating Temp. - 10° —+55° Celcius degree
    Operating Humidity 10 - 90 % RH
    Operating Life 100,000 Hours
    MTBF 5000 Hours
    Protection Level IP65
    Out of Control Pixel Rate 0.01%
    Input Signal Support Composite, S-Video,Component,VGA, DVI,HDMI,SDI,HD_SDI
    Control Distance UTP CAT5E:100m; Multi-mode Fiber:500m;Single-mode Fiber:10km
    Support VGA Mode 800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200,
    Brightness Correction Dot by Dot,module by module, cabinet by cabinet
    Control Mode Synchronous display with control PC by DVI



    ♦ Applications



     --- Outdoor and indoor advertising, digital billboards, advertising companies
     --- Sports halls, fields, playgrounds,school church
     --- Airports, bus stations and railway passenger terminals.
     --- Facades of shopping malls, department stores, banks and car dealerships.
     --- Architecture and social projects, information systems in cities.
     --- Show-business, concerts, festivals, motor shows and other public events.





    High Resolution Excellent Quality SMD Rental Led Screen Full Color 40000 Pixel Density Production process:

    1) Incoming Inspection→2)SMD→3)Plug-in

    →4) Wave Soldering→5)After Welding→6)Testing

    →7) Semi Finished Aging→8)Module Assembly

    →9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 0

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 1

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 2





    High Resolution Excellent Quality SMD Rental Led Screen Full Color 40000 Pixel Density Packaging and Shipping



    Wooden case or flight case package are available.

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 3

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 4





    Shipping by sea,air or DHL,multiple shipping ways for your choice.

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 5





    High Resolution Excellent Quality SMD Rental Led Screen Full Color 40000 Pixel Density Certifications:

    2020 super popular High definition COB GOB waterproof anti-collision small Pixel curve adversiging led screen 6



    Why choose us:



    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.



    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.



    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.



    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.
