P4 High Brightness SMD Indoor Rental LED Display for fixing installation

P4 High Brightness SMD Indoor Rental LED Display for fixing installation



SCXK leads the way in LED display manufacturing & technology. Its outdoor & indoor commercial advertising LED display, rental use LED display, fixed installation LED display, sports stadium perimeter LED display, mobile trailer LED display, water floating LED display, transparent LED curtain display, digital LED billboard, LED mesh display screen for skyscraper's decoration, arc LED display, LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.



We offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality. Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.





the outdoor full color P4 Led display specification
LED Lamps	Type			SMD3535(High Brightness LEDs)
	LED Standard			Real Pixel(1R1G1B)
	Red Wavelength			625-630nm
	Green Wavelength			515-530nm
	Blue Wavelength			465-475nm
LED Module	Pixel Pitch			4mm
	Module Size			256mmx128mm
	Module Resolution			64*32dots
LED Cabinet	Cabinet Size			768mmX512mm
	Cabinet Resolution			192pixels *128pixels
	Cabinets Material			Sealed Iron Cabinet
LED Display	Pixel Density			62500pixels/sq.m
	Drive IC			MBI5124
	Power Supply			Series connection
	Brightness			>7500cd/sqm
	Display Color			16.7million
	Viewing Angle			110°(Horizontal),50°(Vertical)
	Best Viewing Distance			2m~200m
	Max Power Consumption			600 w/sq.m
	Average Consumption			300 w/sq.m
	Weight			40Kgs/sq.m
	Refresh Rate			3000hz
	Input Voltage			AC220V/50H or AC110V/60H
	Output Voltage			DC5V,40A
	Grey Scale Levels			16bit
	Display Colors			R(1024) x G(1024) x B(1024)
	MTBF			10,000 hours
	Life-span			100,000 hours
	Protection Level			IP65
	Failure leds			less than 0.0003
	Working Temperature			-25℃~65℃
	Drive Mode			1/8scaning
	Working Humidity			5%~99%
Control System	Control method			Synchronization & Asynchronization
	Control System			LINSN Control System (sender,receiver,HUB with 75 interface,software) ( within xinxun Asynchronization)
	Software			LED Studio (LINSN)
	Input Signal			MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
	PC Operating system			Microsoft Windows 7, 98, 2000, XP and Vista







♦ Our advantages

Professional Manufacturer of led display



1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 6-8 working days

8. Excellent R&D team,factory Price and assure you quality goods.



♦ Production process:



1) Incoming Inspection→2)SMD→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing





♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.



♦ Packaging and shipping







we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.

we can choose the best shippment which is convenient to you!

SCXK group can give you the short delivery time and With the large production ability ,

you can feel free about this . By air ,by train, by sea?







♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.





Thank you very much for viewing our website, welcome to contact me!
