Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | ShenZhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P8 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | Western Union, MoneyGram, D/P, T/T, L/C |
| Supply Ability: | 5000sqm per month |
| Pixels: | 8mm | Tube Chip Color: | Full Color |
|---|---|---|---|
| Led Type: | SMD 3528 | Display Function: | Video |
| Module Resolution: | 32x16dots | Cabinet: | Steel Or Aluminum For Options |
| The Optimum Viewing Angel: | H:110°,V:60° | Relative Humidity: | ≤95%RH |
| Power Supply: | AC80-260V±10%/50Hz,60Hz | Regular Cabinet Size: | 1024mmx768mm |
| Module Size: | 256mmx128mm | Warranty Time: | 3 Years |
| IC: | MBI 5024 IC | Density: | 15625dots/㎡ |
| Chip Brand: | Epistar Led | ||
| High Light: | advertising led display board,advertising led billboard |
||
SMD3535 Full Color P8 Led Screen Commercial Advertising LED Billboards
P8 Advertising LED Screens Features
1) Reliable quality, advanced and mature technology, compliant with industrial standards and technology developing trend.
2) Good heat emission, water proof and stable performance.
3) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal.
4) High resolution and definition of screen image, clear and non-flash screen image.
5) Supports video and radio frequency input, special structure can be freely assembled.
The Warranty of P8 Advertising LED Screens
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!
Brief Introduction of Our Company
1) SCXK has been specialized in LED field since 2005. We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.
2) We have a professional team and a series of equipments.Every year our products exported overseas and are popular among many foreign countries,also in our own country you can find the many application places.Such as station,airport,church,shopping mall,commercial centure,concert and so on.
3) From statium to TV station,conference&events,SCXK Electronics provide a wide range of eye-catching and energy saving LED screen solutions to industrial,commercial and governmental markets worldwide.
P8 Advertising LED Screens Technical specification
| outdoor SMD p8 | |
| Resolution/mm | 8 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 156250m2 |
| Module resolution64 | 32*16 |
| Module size/mm | 256*128 |
| View distance | 9-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >8000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 scan |
| Frame rate | 60Hz |
| Refresh frequency | 3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | >72hours |
| Mean time Between Failure | >500hours |
| life time | >100000hours |
| Envirornment temperature range | operating temperature range -200c-500c |
| Maximun power :/m2 | -<800w |
| Average power:/m2 | <300w |
| Self-check technolog | LEDspot self-check,communication check,power check,temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control,record potential fault send out warning signs to the operators(need customization) |
| Software environment | windows NT,Windows 1999,Windows XP |
Workshop Show
FAQ
Q1:How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q2: How to proceed an order for led display?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q3: Is it OK to print my logo on led display product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our products.
