Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535

Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535

    • Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535
    • Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535
  • Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1sqm
    Price: negotiation
    Packaging Details: flight case, wooden case
    Delivery Time: 7-10 working days
    Payment Terms: T/T
    Contact Now
    Detailed Product Description
    Pixel Density: 15625 Brightness: 7000
    Control System: LSN LED Shape & Size: 3mm Smd3535
    Module Size: 256*128 Driver Mode: 1/4 Scan
    Operation Power: 220V 60HZ Display Color: 1.07 Billion
    High Light:

    advertising led display board


    advertising led billboard

    Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535


    1.Wide application field & short ROI time:
    commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
    2. High Contrast ratio: 4000:1
    Which is a very high level to ensure a vivid image of our LED display screen system.
    3. First-class LED chip:
    Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system
    4. Clear vivid image quality:
    Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.::
    5. Long-term Brightness:
    Automatic or manual adjustment of the brightness of the display.
    6. Easy Installation & Using:
    easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
    7. Convenient Servicing:
    Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion



    Module Size 256mmx128mm View Angle 120 0/600
    Module resolution 32x16pixel Working Environment Temp:-20°C~60°C, Humidity:10%~90%
    Dot density 15,625pixel/sq. m Working Voltage AC:100V~120V AC:220~240V
    Pixel configuration 1R1G1B Lifetime 100,000Hours
    The best view distance >6M Gray Scale 14bit/color
    Cabinet dimension 640mmx640mm(Optional) Color Display 1.07Billion
    Cabinet resolution 80X80 Brightness ≥7000nit
    Cabinet weight 30-58KG/sq. m MITBF 0.00001
    Drive mode Constant current,1/4 Scan IP IP65
    Max Power Consumption 850W/sq. m Warranty 2-5 years
    LED Parameter R:d(625-630nm) R:IV(400-450mcd) G:d(522.5-525nm) G:IV(1800-2200mcd) B:d(467.5-470nm) B:IV(350-400mcd)
    Image adjustment Brightness, contrast, tone, color range etc
    Brightness uniformity Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness)
    Effective control distance Cat 5<100M / Multi-mode fiber:<500M / Single-mode fiber<20Km
    Color Temperature/contrast Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable
    Control system Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional)


































    Outdoor P8 Advertising LED Screens / Epistar Chip rgb led panel display SMD3535 0


    1. New design for advertising. Portable led display. It's very eay to move from one place to another.


    2. Truck display can be installed in different climate areas all over the world. Low temperature as -20 degree and high temperature as +60 degree, high humidity and high salty air environment such as seaside, our cabinet is oisture-proof and salt-proof.


    3. High brightness DIP LED is widely use for mobile truck led display with weatherproof design, so can be used outdoor with cute weather. Meanwhile, vivid color performance and high conformity would bring an excellent display effect for the event.


    4. Anti-shock, make it's longer lifetime for truck mobile use.


    5. Widely used in rental market, ideal for advertising in busy street or intersections, conference, shows, concerts, sporting event, grand opening, exhibitions, political rallies, elections etc.



    Company Information
    Shenzhen SCXK Electronics Co.,Ltd has the standard new factory,and about 100 employees.
    We have outstanding R&D department and after-sell service workers,and separately design ability.
    Our product mainly included led single dual color display,led indoor full color display;led outdoor full color display,led wireless car used screen etc.It can be used on the shopping more,bank,bus station,train station,Center of downtown,airport,school,factory,bus,taxi and son on.
    We adapt many methods and very good after-sell service to sell our product all over the world.
    Whenever and wherever we are,we always take the principle that is:professional makes good quality,good price product market to provide perfect product and service for our customers.



    1.Q:Are you a factory or trading company?
    A:We are a factory,located in Dalang,Longhua District .

    2.Q:What kind of payment terms you accept?
    A:We accept T/T,Western Union,MoneyGram etc.

    3.Q:What's packaging?
    A:1.Flight case packaging
    2.Wooden case packaging
    3. 36pcs in one case packaging
    4.Customized packaging

    4.Q:Does you have CE/ROHS certificates?
    A:Yes, we offer the CE & ROHS certificates .

    5.Q:What's the shipping method,shipping time?
    A:Our products could be shipped by Sea, by Air, and by Express.
    by sea:20-40days; by air:5-10days ;by express:3-6days

    skype: jonniloc
    whatsapp: +86-13244742283
