Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.

|
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE,ROHS ,FCC,UL ISO2001 |
| Model Number: | SCXK-P16 |
| Minimum Order Quantity: | 1sqm can be available |
|---|---|
| Price: | negotiation |
| Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
| Delivery Time: | 7-10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
| Supply Ability: | 1000sqm/month. we can make the led display on time |
| Cabinet Size: | 1024mmx1024mm | Display Color: | 16.7million |
|---|---|---|---|
| Usage: | Video And Picture Usage | Drive Mode: | Static Scan |
| Module Size: | 256mm X256mm | Color: | Full Color |
| Control System: | Synchronization And A Synchronization | Led Lamp: | DIP346 |
| Material: | Iron And Steel Cabinet | ||
| Highlight: | rgb led screen,full color outdoor led display |
||
P16 DIP346 RGB Led Display Outdoor Led Billboard Water - Proof Cabinet
We really cherish the business relationship with all customers. And provide our best to service every potential customer.
The effect of the outdoor led display is perfect. If you can give us one choice to cooperate with you You will gain a good business partner forever.
Product Features
1.color spots or picture shade will be removed through the adjustment of brightness and color by each independent pixel
2, adopted with self developed steel structure and special kits will be kept in good flatness and smoothness
3, strict water proof testing by Ip65
4, according to environmental changes the brightness can be adjusted automatically for energy saving
5, special PVC kits are adopted to protect from corrosion according to coastal weather
6, according to environmental changes the brightness can be adjusted automatically for energy saving
7, auto power on/off, work unattended
The outdoor P16 led display parameter as follows
| configure | Specification | Parameter |
| Pixel | Dot Pitch | 16mm |
| Pixel Configure | 1R1G1B | |
| Pixel/SQM | 3906Pixel/m² | |
| LED Lamp | LED TYPE | DIP346 |
| Chip Brand | EPISTAR | |
| Wavelength & Brightness | Red:620-622.5nm;>300mcdGreen:520-522.5nm;>600mcdBlue:465-467.5nm;>110mcd | |
| Module | Module Resolution | 16Pixel * 16Pixel |
| Drive Mode | Constant Current Drive | |
| Scanning Method | static Scanning | |
| Module Dimension | 160mm(Width)x160mm(Height) | |
| Drive IC | MBI5024(Or other Similar IC) | |
| LED & Drive Composition | Light-Drive Combo | |
| Refresh Rate | >1500HZ | |
| Cabinet | Cabinet Thickness | 150mm |
| Cabinet Construction | Normal Standard Cabinet | |
| Cabinet Assembly | Connecting Sheet | |
| Cabinet Color(Front/Back) | Black,Grey | |
| Aviation Plug | wp20 | |
| Maintenance Mode | Back Maintenance | |
| Cabinet Material | Spcc1.5 | |
| Cabinet Dimension | 1024X1024X150mm | |
| Power Supply | China Power Supply | |
| LED Screen | Viewing Angle | Horizontal : 120 ° Vertical: 120 ° |
| Brightness | >6000cd/m² | |
| Best Viewing Distance | 16~25m | |
| LED Life | 100,000Hours | |
| Maximum Power | 800w/m² | |
| Average Power | 350w/m² | |
| Input Voltage | 220V±10% Or 110V±10% | |
| Operation Environment | Temperature: —20°C~60°C; Humidity: 10%~95% | |
| Protection Grade | IP65 | |
| LED Screen Weight |
55kg/m2
|
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
