Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE/ROHS/FCC/ISO/UL |
Model Number: | P5 |
Minimum Order Quantity: | negotiation |
---|---|
Price: | negotiation |
Packaging Details: | flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after receive your payment |
Payment Terms: | T/T or western Union |
Supply Ability: | 5000sqm per month |
Product Name: | P5 Led Display | Module Size(W * H): | 160mm*160mm |
---|---|---|---|
Standard: | CE/ROHS/FCC/ISO2001 | Tube Chip Color: | Full Color |
Pixel Pitch: | 5mm | Module Qty: | 1pcs |
Type: | Free Standing | Resolution(W*H): | 32dots*32dots |
Highlight: | rgb led screen,full color outdoor led display |
Large Energy Saving RGB Led Dispaly P5 For Government / Entertainment Project commercial advertising led display
About our factory:
Shenzhen Shichuangxinke Electronic Co.,Ltd was founded in 2005, is headquartered in Shenzhen, China.
we have been exported to USA,Canada,Argentina,Brazil,Ecuador,Venezuela,Honduras,Germany,Spain,
Moldova,Poland,Netherlands,Russia,Sweden,France,Belgium,Turkey,Israel,Saudi Arabia,South Africa,Uganda,Egypt,Angola,India,Vietnam,Thailand,New Zealand,Australia and other 50 countries and regions,and gained a great reputation from customers.
We will do better and we will achieve higher.SCXK LED will strongly promote the channel construction, the channel objectives are: to provide one-stop service to any demand customers.
As one of the professional manufacturers of LED industry, SCXK Group Limited has a high quality, professional and strong production team, market-oriented, constantly innovate based company not only manufacturing technology in traditional LED display screen, constantly improve product cost benefit and market competition, but in the special use of the display technology has a breakthrough.
Our Service
1)Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment
2) Installation and debugging
BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.
3) Warranty
Warranty: 2 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges
After maintenance period, only charge the material cost and labor cost.
Specifications
p5 led module | |||
LED Module | Display | ||
Type | SMD 3in1 | Max.power consumption | Max 1200W/sq.m |
Pixel configuration | 1R1G1B | Avg.power consumption | Max 600W/sq.m |
Drive mode | 1/8 scanning | Max.current. | Max 5.02A/220V, 50HZ |
Module Re.(Dot) | 32*32(W*H) | H/V viewing angle | 120/120 |
Pixel pitch(mm) | 5mm | Brightness(CD) | Min 1300cd |
Module size(mm) | 160mm*160mm(W*H) | Pixel density(Dot) | 111111 |
Cabinet | Power factor | Min 0.7 | |
LED board array |
32*32(W*H) |
Cert. | UL,CE,ETL,ROHS |
Cabinet Re.(Dot) | 128*128(W*H) | Contrast | 2000:01:00 |
Cabinet area | 0.4096 sq.m | Working temperature | -10--50 |
Cabinet size | 640*640mm(W*H) | Working humidity | 20% to 90% |
Weight | 18kg Alumimum/Cild rolled sheet | Lifespan(50%) | 100,000hours |
Power | AC220/110,47~63HZ | Processing | 10 bit |
Frame rate | 60 fps | Colors | 687 billion |
Dimming level | Manual-100 levels, Automatic-16 levels | Refresh frequency | Min 800Hz |
♦ Production process:
→1) Incoming Inspection→2)SMD→3)Plug-in
→4) Wave Soldering→5)After Welding→6)Testing
→7) Semi Finished Aging→8)Module Assembly
→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing
♦ Product specification
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
A. Flight case Packing
1)150KG Per flight case
2)3 cabinets in one case
3)Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch
B. Plywood case
1)180KG per plywood case
2)3 cabinets in one case
3)Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch
C.customized packing is acceptable
D. 20"FT container loading of 100sq.m
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-10 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
