products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
LED Dance Floor
Created with Pixso.

Full color Anti-collision LED Tile Screen

Full color Anti-collision LED Tile Screen

Brand Name: SCXK
Model Number: P8.928
MOQ: 1sqm
Price: negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Detail Information
Place of Origin:
CHINA
Certification:
CE/ROHS/FCC/ISO/UL
Pitch:
8.928mm
Module Size:
250*250mm
Pixel:
28*28dots
Pixel Density:
12580mm
Cabinet Size:
500*50mm
Driving Mode:
1/7 Scan Constant Current
Packaging Details:
plywood case, flight case etc, you choose what you like.
Highlight:

club dance floor

,

light up dance floor

Product Description

Full color Anti-collision P8.928 LED Tile Screen Led Dance Floor with affordable price



What is led floor tiles screen ?

LED tile screen is a kind of LED display designed for the ground, it has done a special design for load-bearing, protective properties, and thermal performance so that it can adapt to high-strength stampede, long time normal operation.



LED tile screen applications:

Used in the stage, concerts, performances, bars, disco, shopping malls, etc.



LED tile screen features:

1.Quick and flexible installation: no tools can be installed directly or rail installation.

2. High load-bearing performance: aluminum alloy structure, high load per square meter up to 1.5 tons.

3. Excellent maintenance performance: can be directly exchanged without removing the adjacent box

4. High contrast design: technology design masks, clear playback.

5. Outstanding low light high gray effect, showing uniform grayscale, good consistenc



 Parameter specification

Pixel Pixel pitch 8.928mm
Pixel configuration 1R1G1B
LED Lamp Red Wavelength 180-240M/CD
Green Wavelength 650-850M/CD
Blue Wavelength 80-100M/CD
LED specification SMD3535
Module Module size 250MM*250MM*16MM
Pixel resolution 28dots*28dots
Weight 540g
Cabinet Cabinet size 500MM*500MM*75MM
Cabinet resolution 56dots*56dots
Screen body Driving mode Constant current scaning 1/7
Pixel density 12580dots/ M
Brightness 1600-2400cd/ M
Gray scale 4096 grade
Refresh frequency ≥3840Hz
Span life ≥70000hours
Voltage AC220V±15% 47~64HZ
Maximum power/㎡ 400W/ M
Average power/㎡ 240W/ M
Mean Time Between Failure ≥7000hours
Working temperature -10℃~+60℃
Working humidity 10%-95%RH
Flatness Any adjacent pixels ≤ 0.18mm
Module splicing gap <0.3mm
Effective communication distance network cable 100m
Multimode fiber 500m
Single mode fiber 50km



Module Process

Full color Anti-collision LED Tile Screen 0



Product item
Many other hot product, welcome to visit our company!
Full color Anti-collision LED Tile Screen 1
Full color Anti-collision LED Tile Screen 2



Company profile

Full color Anti-collision LED Tile Screen 3

Full color Anti-collision LED Tile Screen 4



Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.

Full color Anti-collision LED Tile Screen 5


Buying Guides
In order to offer you a suitable solution, please follow the guides bellowing :
1,Star effect or video effect which you need.
2,Dimension (Width and Height)
3,Location of installation. (picture is best)
4,Purpose. ( what are you going to do with the LED Curtain)



After-Sale Service
1. Three year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.
