| Brand Name: | SCXK |
| Model Number: | SCXK-P3 |
| MOQ: | Negotiations |
| Price: | Negotiations |
| Payment Terms: | T/T, L/C, MoneyGram, Western Union, D/A, D/P |
| Supply Ability: | 3000sqs/month |
Indoor P3 Full Color Advertising Screens Video HD 192*192mm Module Aluminum
Quick Detail:
1. Resolution up to 160,000 pixels/㎡;
2. LED chip: Eppistar high brightness;
3. Brightness up to 7000cd/㎡;
4. Power supply: Meanwell; G-nergy, driver led by changlian
5. Control systems: Linsn, Nova, etc.
Description:
1, P2.5 SMD LED display is high resolution for indoor LED screens use;
2, Large viewing angle at 140 degree horizontal and vertical;
3, Eletronic digital sign P2.5 is being used more and more, as LED screens trend is high resolution.
4, Clear and vivid advertising image and video;
5, High contrast ratio at 1000:1 to present true and natural color LED screens;
Applications:
Airport Indoor Full Color LED Display Advertising
Full-color LED display in the train station
Entertainment column indoor full color LED display
Full-color LED display in the gymnasium
Full-color LED display in the museum
Automobile exhibition LED display
Full-color LED video display in the conference room
Full-color LED display in the shopping center
Specifications :
| Indoor Full Color P3 LED Display | |||||
| Resolution/mm | 3 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 111111/square meter | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 192x192MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our advantages:
1. High quality for good price.
2. Quick delivery after payment.
3. Provide free technical support.
4. Warranty for 3-5 years.
5. If any questions,we'll replay and solve it in 24 hours.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
![]()
![]()
![]()
![]()
![]()
![]()
