P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm

P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm

  • P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm
  • P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm
P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P1.923
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T or western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: Led Display Module Module Size(W * H): 246mm*246mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 1.923mm Type: Free Standing
Resolution(W*H): 128dots*128dots
High Light:

led screen module

,

rgb led display module

P1.923 SMD LED Module , 1/32 scanning Full Color LED Module 246*246mm



Delivered Product List

Fixed-installation indoor/outdoor LED display

Rental LED video display

LED Curtain Display/LED Bar Display

Stadium Perimeter LED Display

Vehicle-carried/Mobile LED Display

Traffic Guidance LED Display



LED Display Mainframe Installation

P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm 0



The above six types are commonly used for LED Display installation. Types of A B C E are frequently used for indoor display installation and all the six types can be used for outdoor display installation.





Warranty



Shenzhen SCXK electronics Technology Co., Ltd. warrants only to the original buyers of its products from the company or ASWEI -authorized resellers or distributors that all its products are new, complete and never being used and that all the technical information it provides regarding its contracted products is complete, clear and correct.



Warranty coverage:



The user of ASWEI display system shall contact the company within reasonable period of time if any problem is found that can’t be solved by the users. Shenzhen SCXK is responsible for the quality of its display system that is under normal use and storage and shall repair or replace at its disposal any failed parts .The user is obligated to provide ASWEI with a written report detailing the trouble or failure.



Disclaimer of Warranty



This warranty doesn’t cover problems caused by or in following conditions:



A. The normal wear or aging of parts and the whole display system.

B. Problems or damages caused by or due to unauthorized alteration, misuse, abuse and/or negligence.

C. Problems or damages caused by or due to force majeure.




P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm 1



The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
The steel consturction is very stable for led display,and you can purchase from your local market .



The detailed parameter as follows.


1,  Item Name

P1.923 indoor SMD LED Display Module size 246*246mm 1/32 scanning

2,  pixel tube:

   pixel pitch:1.923mm;  primary colors: pure red+pure green+pure blue ,
   color composing: 1R1G1B
   Density:270420dots/sq m;

3 , unit box

  module size:246mm×246mm;  Module resolution:128*128
  cabinet thickness:(cold-roll steel sheet)150mm+(maintain)600mm;

4, whole screen:

the optimum viewing angel :horizontal 110°, vertical 50°
viewing distance:>15m;working temperature:-20°C~+45°C(-30°C ~+50°C  optional)    relative humidity:≤95%RH;   Drive IC ET6024


5, operating voltage

AC220V±10% or 110V±10% ,average consumption:500 W/sq m
  max consumption:≤650 W/ sq m

6, main parameter

1) driving mode: 1/32 scanning
2) refreshing rate:≥400Hz/s
3) frame frequency:≥60Hz/s
4) gray scale/color:≥16.7Mcolors(Synchronized)
5) manage gray:≥72bit
6) brightness:≥1500cd/sq m
7) color temperature condition:3500K~9500K,be adjustable
8) adjusting style of brightness: hand movement/auto
9) video signal: RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc. managing ability of signal:≥12bit.against Y revised curve: owns 3pcs above Y curve that can adjustable.
10) average trouble-free time:≥5000hours
11) evenness: between random adjacent pixel ≤0.5mm,module splicing space<1mm
12) switch power loading:5V/40A
13) display mode of computer:1024×768


competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.



Methods for Quality Assurance
a. Aging
1. 100% fully test

  1. Condition: 72 hours with 256 gray level

b. Vibration Testing
Condition: 3-5 min up and down in 5mm range



Company information
About us.jpg
Order Procedure
Negotiation---First solution recommended---Finalize all the details---30%deposit in advance or full deposit---
Start production---Pay the balance---shipment by DHL--provide tracking number---feedback.

Parking and Shipping
A. Flight case Packing
1)150KG Per flight case
2)3 cabinets in one case
3)Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch

B. Plywood case
1)180KG per plywood case
2)3 cabinets in one case
3)Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch

C.customized packing is acceptable
D. 20"FT container loading of 100sq.m

1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.


Production Flow


Shenzhen ShiChuangXinKe Electronics Co.,Ltd. always lead the new
development of technologies, new products and value-added services. Over the years,
many kinds of led display have been created, applied, and enable real growth for
customers into new market places.





Any question,do not hesitate to contact me,i am always here for you.
P1.923 SMD led display module , 1/32 scanning Full Color LED Module 246*246mm 6
