Full Color RGB IP65 Waterproof LED Display Screen with Customized Size for Outdoor Advertising

Brand Name:	SCXK
Model Number:	SCXK-P5
MOQ:	5sqm
Price:	negotiation
Payment Terms:	D/P,T/T,Western Union,MoneyGram
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

made in china

Certification:

CE/ROHS/FCC/ISO/UL

Material:

Steel And Aluminum

Waterproof Rating:

IP65

Module Size:

320mm*160mm

Pixel Pitch:

5mm

Brightness:

5000 Cd/m²

Working Voltage:

AC220V±10% 47HZ~60hz

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led display smd

smd led display

Product Description

Full Color Large P5 Outdoor LED Display Screens Big TV Advertising LED Billboard

Nationstar lamps full color large P5 outdoor LED display screens Big TV Advertising LED Billboard

With 12 years of production experience, we offer comprehensive solutions including installation and after-sales service. We carefully select materials suitable for various environmental conditions, from extreme cold temperatures of -25℃ to hot temperatures up to +55℃. Our expertise extends to cables, LED lamps, plastic masks, waterproof materials, IC components, and more. We provide flexible, diverse solutions to meet varied requirements and offer 24-hour online support.

Basic Introduction

High IP Level Safety and Stability

IP65 protection rating ensures safety in all weather conditions
Professional aviation plug connectors guarantee quality connections
High-quality raw materials, mature craftsmanship, and large-scale production ensure reliable quality

Super Wide Viewing Angle With Exquisite Image Quality

Best LED industrial waterproof and ultraviolet-proof SMD 3-in-1 technology for super wide viewing angles
Enhanced surface flatness and stability during screen operation
RGB deep gray processing delivers colorful and exquisite images
Point-to-point correction function ensures consistent color and brightness throughout usage

Technical Specifications

Items	P5 Outdoor Full Color Display
Module
Pixel Pitch	5mm
Pixel Density (dot/m²)	20000
Pixel Configuration	1(RGB)
Packaged Type of LED	SMD
Module Size (mm)	160×160
Module Resolution	32×32
Technical Parameter
Brightness (cd/m²)	5000
Max Power Consumption (w/m²)	1050
Best Viewing Distance (m)	6-18
Viewing Angle	120°V/120°H
Drive Mode	Constant Current drive 1/8 scan
Driving	Driving IC MBI5026GF
Frame-change Frequency	≥60 Hz/s
Refresh Rate	≥600Hz/s
Gray Grade Level	4096 grades
Color	65536 kinds of colors
Display Mode	192×192
Control System	Synchronization Control
Transmission Distance	Reticle≤100M; Multi-mode Fiber≤500M; Single-mode Fiber≤10000M
Out of Control Rate	≤0.0001
Lifespan	≥100000H
Driving Power	5V
Working Voltage	AC220V±10% 47HZ~60hz
Working Temperature	-10ºC~+55ºC
Working Humidity	5%RH~85%RH

Methods for Quality Assurance

Aging Test

100% fully tested under the following conditions: 72 hours with 256 gray level

Vibration Testing

Testing conditions: 3-5 minutes up and down in 5mm range

Order Procedure

Negotiation → First solution recommended → Finalize all details → 30% deposit in advance or full deposit → Start production → Pay the balance → Shipment by DHL → Provide tracking number → Feedback

Payment and Delivery

T/T: 30% deposit, 70% before shipment
100% Western Union in advance

Production Flow

Frequently Asked Questions

What kind of payment terms do you accept?

We accept T/T and Western Union payments.

What about your LED Display quality?

Quality is ensured through comprehensive checking throughout the manufacturing process and 100% inspection before shipment.

What is your delivery time?

Delivery time ranges from 7-35 days depending on your location and order quantity.

Is your LED display competitive?

Yes, as an LED display manufacturer with over 10 years of experience, our mass and professional production ensures competitive pricing and quality.
