Indoor Full Color LED Display
Created with Pixso.

Indoor Rental LED Display P2.5 SMD Full color Die cast aluminum 640mm x 640mm cabinets

Indoor Rental LED Display P2.5 SMD Full color Die cast aluminum 640mm x 640mm cabinets

Brand Name: SCXK
Model Number: P2.5
MOQ: 1 sqms
Price: negotiation
Payment Terms: T/T
Supply Ability: 3000 sqm per month
Detail Information
Place of Origin:
China
Certification:
CE/ROHS/FCC/ISO/UL
Module Size:
320*160
Protection Level:
IP34
LED Shape & Size:
2mm Smd2121
Brightness:
2200
Pixel Density:
160000
Driver Mode:
1/32
View Angle:
120° / 60°
Packaging Details:
flight case, wooden case
Highlight:

led video screen rental

,

led rental screen

Product Description

Shenzhen full color tv panel led video wall indoor P2.5



Usage for indoor

1.Sports

2.Advertisement

3.Enterainment

4.Stage& Events& Rental

5.TV Studio







Pixel pitch P2.5
Module Parameters Pixel pitch 2.5 mm
Pixel Density 160000 pixels/m2
LED Shape SMD 3in1
LED Configuration 1R1G1B
Module Resolution 96*96 pixel
Module Size 240*240 mm
Drive Method 1/16, 1/24, 1/32
Cabinet Parameters Cabinet Resoltuion 192*192
Cabinet Size 480*480 mm
Cabinet Weight 4.5 kg

Display

Parameters

Optical Brightness ≥1200 cd/m2
Viewing angle H/V 160/160
Best Viewing Distance 2.5-15 m
Display Color 16.7 million
Grey Scale 10bits/1024levels
Power Max power consumption 1000 W/m2
Ave power consumption 500 W/m2
Working Voltage 220V / 110V
Control system Frame Frequency 60--85 HZ
Refresh Rate 4000 HZ
Data Transmission CAT 5/ Optic Fiber
Image Source S-Video, PAL/ NTSC
Controlling system linsn, Nova, Mooncell
Format Video Compatibility DVI, VGA, composite
Reliability Working Temperature -20~65 ℃
Working Humidity 10-95% RH
Life Span 100,000 Hours
MTBF (Ave No Faliure Time) 5000 Hours
Pixel failing Rate 0.01%
IP Rate IP 34



Features



1. The fast lock, easy to installation

2. High brightness, Excellent gray scale, Well showing effect, IP65 for outdoor using

3. Can play images, graphics, HD video, video singal from other equipments

4. Good lightening accordance and no mosaic

5. 2 years warranty



Specification



Module Size: 160mm*160mm

Cabinet Size: 480mm*480mm

Screen Size: Customized

Service



1. We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.

2. We provide technology training for free, which contains the operation and maintenance training of the LED

screens in the factory.

3. After warranty , we also can offer you the parts for replacement at our bottom price.

4. After sales, if you have any problem about our product,you can inform us by Email, we will reply you at once when we get it and offer you a good solution to solve the problem.

5. We also could solve problems for you until it recovers well by remote control!



Applications



Mainly for indoor using, information publishing, journalism and communication.



eg: studio, meeting room, bank, monitor room, information centers

entertainment venues, etc

Company Information

Shenzhen SCXK Electronics Co.,Ltd has the standard new factory,and about 100 employees.
We have outstanding R&D department and after-sell service workers,and separately design ability.
Our product mainly included led single dual color display,led indoor full color display;led outdoor full color display,led wireless car used screen etc.It can be used on the shopping more,bank,bus station,train station,Center of downtown,airport,school,factory,bus,taxi and son on.
We adapt many methods and very good after-sell service to sell our product all over the world.
Whenever and wherever we are,we always take the principle that is:professional makes good quality,good price product market to provide perfect product and service for our customers.



Indoor Rental LED Display P2.5 SMD Full color Die cast aluminum 640mm x 640mm cabinets 0

FAQ

1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3. 36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days
