Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P5 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD600-1800 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 5 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/8 Scanning | Module Size: | 320x160mm |
| Certificates: | CE RoHS FCC CCC UL | Application: | Stadium,airport,shopping Mall,street Advertising |
| Material: | Aluminum | Warranty: | 3-5 Years |
| Cabinet Size: | 640x640mm/800x800mm | ||
| Highlight: | led full color screen,indoor led billboard |
||
SMD 960x960mm cabinet RGB full color kinglight P5 LED Message Display Board
Features:
1. Lightweight: Aluminum alloy die-casting process, weighing about 8kg, easy to install and disassemble
2. High refresh rate: Refresh rate above 1200Hz, ensuring the picture is wrinkle-free, line-free and stable.
3. Low brightness and high grayscale: 14Bit-16Bit grayscale, excellent performance can still be achieved when the brightness is reduced by 25%.
4. Easy installation: No need to worry about installation, the installation is very simple because of the die-cast cabinet design, just like building blocks
5. High IP: IP65 ensures reliable operation in different environments, safer
6. Low brightness and high grayscale: 14Bit-16Bit grayscale brings perfect display performance, no shadow advantages:
1.8-year factory, we are an 8-year LED screen manufacturer, we have rich experience in outdoor and indoor LED display screens, and the quality is guaranteed
2. Price advantage, we have stable suppliers, and we have achieved economies of scale, so our cost is lower than some of our competitors, trading companies and middlemen
3. Our sales staff are professional and will provide detailed answers to your questions. We have a strong technical team to meet your special needs, such as OEM and ODM services
4. Our purpose: Put customers in mind, customer requirements are our foundation, we develop different solutions according to different requirements of customers
Specifications :
| outdoor SMD P5 | |||||
| Resolution/mm | 5 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 4000/m² | ||||
| Module resolution | 64x32 | ||||
| Module size/mm | 320x160mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
The best service from our team.
If you don't want to waste time making a choice or have difficulty choosing, just answer our three simple questions and our team will provide you with the most suitable solution.
(1) What size screen do you want to make?
Height = ( ) mm, Weight = ( ) mm
(2) Where do you want to install it? Indoor or outdoor?
(3) The budget range you want to buy the screen
We will provide you with the original installation connection diagram.
FAQ
Q1: Can you provide OEM or ODM service?
Yes, our company specializes in OEM and ODM services with excellent R&D team, perfect quality and lighting solutions, just tell us what you think.
Q2: What kind of packaging is usually used for this product?
Usually we provide air box packaging (wooden box and flight case are available)
Q3: Can I print my logo on the lamps?
A: Yes, we can print your logo on the lamps for free.
Q 4: Do you offer a warranty on your products?
A: We offer a three-year warranty. The defective rate of our products is less than 0.2%.
Q 5: How long does it take to produce after an order is placed?
A: It depends on the quantity of the order. Most online wholesale orders are shipped within 3-5 days after payment is received.
Q 6: What payment methods do you accept for full orders?
We offer a variety of payment methods including PayPal, Visa, MasterCard, Alibaba Trade Assurance, Western Union, and Wire Transfer (T/T).
