Die-Casting Aluminum Screen 1/7 Scanning 500*1000MM P5.95 LED Advertising Display Rental Fixed Installation

Brand Name:	Shichuangxinke
Model Number:	SCXK-P5.95
MOQ:	negotiation
Price:	negotiation
Payment Terms:	L/C, T/T, Western Union, D/A, MoneyGram
Supply Ability:	3000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

China ,Guang Dong

Certification:

CE RoHS FCC CCC TUV UL

Resolution/mm:

5.95

Pixel Configuration:

1R1G1B

Scanning Mode:

1/7 Scanning

Module Size:

250x250mm

Certificates:

CE RoHS FCC CCC UL

Application:

Stadium,airport,shopping Mall,street Advertising

Material:

Aluminum

Warranty:

3-5 Years

Cabinet Size:

500x1000mm

Packaging Details:

wooden box flight case, wooden case, carton, it is up to you.

Highlight:

full color outdoor led display

outdoor full color led screen

Product Description

500*1000 mm Die Casting Aluminum 1/7 Scan P5.95 LED Advertising Display

Specifications :

outdoor SMD P5.95
Resolution/mm	5.95
Pixel configuration	1R1G1B
Pixel density/pixels/m²	28246/m²
Module resolution	42x42
Module size/mm	250x250mm
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>7500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/7 SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

How do you ship the goods?
As for express way, we adopt DHL FEDEX UPS mainly,

30usd per shipment will be required for remote address

What is the payment method
Alibaba trade assurance, Paypal, WesternUnion, and
T/T method, 25% deposit and the rest shall be paid out before shipment

Can i print my LOGO?
Yes, and we can also provide the package with your logo for mass production

What is the guarantee
We guarantee all our items 3 years

Support and Services:

Our LED Billboards are backed up by our comprehensive technical support and services, which include:

24/7 customer service hotline
On-site installation and training
Remote diagnostic and troubleshooting
Regular maintenance and cleaning
Software and firmware updates
Warranty and after-sales service

We are committed to ensuring that our customers receive the best possible support and services to maximize the performance and lifespan of their LED Billboards.
