Innovative High Definition P4 Led Module Rgb Led Billboard Advertising

Innovative High Definition P4 Led Module Rgb Led Billboard Advertising

Innovative High Definition P4 Led Module Rgb Led Billboard Advertising
Innovative High Definition P4 Led Module Rgb Led Billboard Advertising

Product Details:

Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/SGS
Model Number: P4

Payment & Shipping Terms:

Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Packed in wooden case and flight case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 5,000/ Sq m per month
Contact Now
Detailed Product Description
Product Name: The Single Led Display Module Size(W * H): 256mm*128mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 4mm Resolution(W*H): 64dots*32dots
Led Lamp: Kinglight Led Chip: Epistar
High Light:

outdoor advertising led display

,

advertising led billboard

Innovative High Definition outdoor full color P4 Led Module Rgb Led Billboard Advertising led screen



Product Description

P4 is the our supper hd product of outdoor standard led display series for advertising usage in Shenzhen SCXK Electronics Co., ltd. it adopted high refresh MBI driving IC, SMD1921 led lamps, high-quality power supply and iron or aluminum cabinet, 1/8 scanning mode, brightness can reach 5000 nits, which has many advantages, such as waterproof, high definition, high refresh rate, high gray scale, energy saving, high contrast ratio, safe, stable, quick response, etc. Widely used in small outdoor advertising screen.






Module
specification P4
Pixel pitch 4mm
pixel configuaration 1R1G1B
density 62500 dot/m2
module size 256*128mm
module resolution 64*32 dot
led type SMD2121
brightness more than 5000cd/m2
Cabinet cabinet size customized
cabinet resolution customized
viewing angle H: 120º ; V: 60 º
protective grade IP65
max power consumption 1200w/m2
average power consuption 480w/m2
best viewing distance 4-200m
material steel
Screen operation temperature -15 ℃~55 ℃
operation humidity 10%-90%RH
driving method 1/8 scan
woking voltage AC85~264V(47-63hz)
colors 687 Million Colors
refreash rate 1200hz
smoothness ±0.1mm
MTBF >10,000hr
lifespan >100,000hr
LED failed <0.0001(zero when delivery)
Control system and LED Adopted control system PCTV Board + DVI Board + Control Board + Network cable Transmission
video signal RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc
LED parameter R: (620-623nm) G: (519-522nm) B: (466-467 nm)
R: IV(800-1200mcd) G: IV(1800-2300mcd) B: IV(450-520mcd)
Brightness level Manual adjustment: 256 levels for R, G, B
Automatic adjustment: 16 grades for each color




Product Performance



•Wide adjustability range allows the user to regulate the display brightness for all environmental conditions.

•High degree of color and brightness uniformity provides an amazingly sharp, vivid and clear Image.

•Wide viewing angle up to 110 degrees horizontal and 60 degrees vertical.

•Low energy consumption and rapid heat dissipation aid in extending the product’s life span.

•Easy to maintain with simple module replacement.

Innovative High Definition P4 Led Module Rgb Led Billboard Advertising 0

Innovative High Definition P4 Led Module Rgb Led Billboard Advertising 1





Our Service



1)Training after order

After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment



2) Installation and debugging

BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.



3) Warranty

Warranty: 2 years warranty, lifetime maintenance

Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.



4) Maintenance

Maintenance principles: response in time, solve problems asap and ensure the use.

Maintenance period: In the maintenance period of the led display body, free of all maintenance charges

After maintenance period, only charge the material cost and labor cost.

Innovative High Definition P4 Led Module Rgb Led Billboard Advertising 2
Innovative High Definition P4 Led Module Rgb Led Billboard Advertising 3


Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.



Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. On site installation instruction and regular inspection

6, Small order accepted.



Payment and delivery


1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.



♦ Why choose us:

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.







♦ FAQ



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
