Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P8 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Pixel: | 8mm | Pixel Configuration: | Red Green Blue |
|---|---|---|---|
| Scanning Mode: | 1/4 Scanning Mode | Module Size: | 256x128mm |
| HS Code: | 8528591090 | Application: | Airport,wall,church Wedding,exhibition Stand |
| Driver IC: | MB5024/MB5124 | Warranty: | 2-3 Years |
| Cabinet Size: | 1024x768mm/512x512mm | ||
| Highlight: | full color outdoor led display,outdoor full color led screen |
||
HD Outdoor Full Color P8 SMD LED Moving Sign Display,SMD3535 LED Board Display
★Specifications:
1) High Reliability, Long Durability
2) Excellent Quality,Pass ISO9001:2000
3) Low Power Comsuption, Energy Saving
4) High Brightness,Long Lifespam
5) Timely Delivery, Easy and fast installation
★p8 smd led moving sign display advantage:
1)High refresh rate, high brightness, high contrast, so that the screen in direct sunlight without any delay and smearing phenomenon.2)Energy saving: low-current, high-brightness bulbs, equipped with a PFC switching power supply, power savings of up to 30%.3)Adjustable brightness to adapt to changes in the environment.4)Wide viewing angle: Horizontal and vertical viewing angle is very wide, suitable for wide-format horizontal5)Environmentally friendly: antistatic, dust-proof, heat dissipation is good, cost-effective.6)Error Detection and monitoring: can automatically monitor the internal temperature, voltage, cooling fan, etc., and error detection7) High reliability: the use of distributed scanning technology and modular design technology, reliability and stability is higher8) Stable and reliable system: anti-interference ability, long service life, can work continuously for more than 24 hours, the system is simple to operate9) Effective: the use of point-to-point correction technology, the image is clearer, the (10) display module is easy to install and maintain
★Specifications :
| outdoor SMD P8 | |||||
| Resolution/mm | 8 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 15625/m² | ||||
| Module resolution | 32x16 | ||||
| Module size/mm | 256x128 | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
★Thanks for your time! Wish you have a nice day! Why not contact us for more information and supprise right now! Email, Skype, Trademanager and so on.
Contact Person: Lillian seori
Tel: +8619386814677
