Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P6.67 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Pixel: | 6.67mm | Pixel Configuration: | Red Green Blue |
|---|---|---|---|
| Scanning Mode: | 1/8 | Module Size: | 320x160mm |
| HS Code: | 8528591090 | Application: | Airport,wall,church Wedding,exhibition Stand |
| Driver IC: | MB5024/MB5124 | Warranty: | 2-3 Years |
| Cabinet Size: | 640x640mm | ||
| Highlight: | led advertising billboards,led screen billboard |
||
P6.67 Front Access Module LED Display for Easy Install & Maintenance
Customer Service:
1) Warranty Period: One year after shipment from the factory
2) Warranty coverage: LED modules, power supplies, control systems and other accessories (this warranty does not cover accessories purchased from other manufacturers)
3) Repair Method:
Repair, express delivery, etc.
4) Repair response time:
Repair method: Upon receipt of the returned product, the repair will be completed and returned to the user within 24 hours;
Telephone or Internet: Contact the user within 2 hours after receiving the information, and solve the problem within 8 hours;
On-site mode: (domestic users only) after receiving the repair report, users in Guangdong Province within 48 hours to give a reply, users outside Guangdong Province within 72 hours to give a reply. Under special circumstances, the two sides will solve the problem by friendly negotiation.
| outdoor SMD P6.67 | |||
| Resolution/mm | 6.67 | ||
| Pixel configuration | 1R1G1B | ||
| Pixel density/pixels/m² | 22478/m² | ||
| Module resolution | 48x24 | ||
| Module size/mm | 320x160mm | ||
| View distance | 14-300m | ||
| Single point brightness adjust | Can be added | ||
| Single point color adjust | Can be added | ||
| White balance brightness | >7500cd/㎡ | ||
| Color temperature | 6500K-9500K | ||
| Horizontal view angle | 120(degrees) | ||
| Vertical view angle | 60(degrees) | ||
| Signal Process bit | 10 or 16bit | ||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||
| Driving mode | Constant driving current | ||
| Scanning mode | 1/4SCANNING | ||
| Frame rate | 60Hz | ||
| Refresh frequency | >3000Hz | ||
| Control mode | Computer synchronous | ||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||
| 255 steps. No grey loss | |||
| Out of control point | <1/10000 | ||
| Working hours | ≥72hours | ||
| Mean Time Between Failure | >5000hours | ||
| Life time | 100000hours | ||
| Life-all-white(brightness halving) | 50000hours | ||
| Environment temperature range | Operating temperature range: -20-45℃ | ||
| Self-check technology | LED spot self-check, communications check, power check, | ||
| temperature monitor(need customization) | |||
| Remote monitoring | Remote supervision and control, record potential fault, | ||
| send out warning signs to the operators.(need customization) | |||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||
| Luminous point width between centres | Deviation<3% | ||
| Brightness uniformity | <10% | ||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||
| Power supply request | AC85-264V(50Hz-60Hz) | ||
| Contrast | (1000:1) | ||
| System protection |
Moistureproof,dustproof,high temperature protection, anti-corrosion,anti-burning,anti-static,anti-vibration |
||
| Humidity(working) | working:10-95% | ||
| Humidity(storing) | storing:10-95% | ||
Advantages:
1. High temperature resistant and aging resistant PC materials are applied in the modules to get rid of the mosaic problem even after long time use.
2. High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3. The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.
Contact Person: Lillian seori
Tel: +8619386814677
