Home ProductsIndoor Full Color LED Display

Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall

Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall

    • Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall
    • Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall
  • Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall

    Product Details:

    Place of Origin: ShenZhen in China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: Western Union, MoneyGram, D/P, T/T, L/C
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixels: 5mm Tube Chip Color: Full Color
    Led Type: SMD3535 Display Function: Video
    Waterproof: Ip65 Cabinet: Die Casting
    MBI: 51024 Viewing Angle: H:100 V:50
    Optimal Viewing Distance: >=4m Voltage: DC5V
    Brightness: More Than 2000cd/㎡ Pixel Composing: 1 R1G1B
    LED Parameter: R:625-630nm Module: 160*160mm
    Cabinet: 640*640mm

    Product parameter list



    Pixel Pitch 5mm
    pixel Density 40000dots/sqm
    Pixel Configuration 1R1GB(LED SMD 3528)
    Size of LED Cabinet 480mm*480mm=0.2304m2
    Cabinet Resolution 96*96dots
    Cabinet thickness 60mm
    Cabinet Weight 9.5kg
    Max Power Consumption 1500w/m2
    Average Power Consumption 750w/m2
    Earth Leakge Current <3mA
    Drive Type 1/8 Scan Constant Current
    Brightness ≥2500cd/ m2
    Color Temperature 6500-9500K
    Best Viewing Distance 4m-30m
    Cray Scale 12bit
    Color Scale 36bit
    Refresh Rate ≥1000Hz
    Best Viewing Angle Horizontal 120°,Vertical 120°
    Color Conformity <4°
    Control Mode Synchronous control by computer
    Conmmunication Distance Cat5 network cable transmission:100meters;Multimode Optical
    Malfunction Dot Rate <1/10000
    Average No Failure Time >10000H
    Life-Span >10000H
    Working Voltage AC220V/50HZ,AC110V/60HZ optional
    Working Temperature -20°C- +60°C
    Working Humidity 10%-90%
    Input Signal RF, S-Video, VGA, DVI, RGBHV, Composite, TV,HDMI, SDI, HDSDI etc.

    Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall

    Die Casting Aluminum outdoor Rental Led Display Screen P5 smd Led Video Wall



    Packaging & Shipping

    LED Video Wall/ LED Stage Background Display Screen/Indoor Rental LED Videowall



    FAQ

    Q1: What's the warranty of your LED Display Screen ?

    A1: We have a 2-year warranty for our led display screen, and 100,000 hours life span of the led lamps.


    Q2: What about your pre-sale service and post-sale service?

    A2: For pre-sale service: We have a professional sales team and more than 10 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!

    For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

    Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!



    Q3: Whats your payment term? How long it takes to delivery?

    A3: We accept T/T and L/C, 30% deposit in advance, and the rest 70% before delivery.

    Our average Production time is 15 days, after receiving the deposit.



    Q4: What's the control system?

    A4: We use popular control system like Nova , Linsn.


    Q5: How can you ensure the led display product quality?

    A5: Our led display screen quality is our core competence, for 12 years, what we rely on.

    We have each stardard process to make quality products

    strictly total quality management-ISO management system , including incoming quality control and input process quality control and for outdoor products we have "stromtest " reliability test program and "stromtest " reliability test system .



    We build what you can rely on !
