Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P25 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 400-750 square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 25mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | Static Full Color | Module Size: | 200x200mm |
| Cabinet Size: | 1600x1200mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 2-3 Years | ||
| Highlight: | full color led signs outdoor,outdoor full color led screen |
||
P25 DIP LED Display factory direct wholesale cheap price for india market
Introduction:
SCX specializes in the production of stadium LED wall displays. Currently, we focus on P25mm DIP wall displays. The module mask adopts post-molding technology to withstand various impacts; the cabinet is exquisitely designed, integrating rental, wall and fixed installation structures.
Features:
1. The waterproof protective layer adopts silicone rubber. This material has high thermal stability. We designed a three-layer protective structure to be waterproof.
2. The soft mask has high impact resistance. The mask protective layer adopts a buffer arc structure to withstand the impact of football, tennis and players.
3. New structural design. It can meet the needs of rental, wall and fixed installation. This multi-functional cabinet enables the new product to be easily and conveniently applied to different occasions. This structure makes the cabinet connection joint smaller. During the hanging process.
3. New color matching, the color contrast of the black cabinet and the silver-gray door panel makes the LED screen more elegant
4. Angle-adjustable rear bracket, users can adjust the audience's best display viewing angle through the bracket. The bracket can be folded on the cabinet during rental and fixed installation.
5. There is a rubber protective pad on the top of the box to protect the player from injury.
6. The box is made of aluminum alloy to reduce weight and make it easy to move from one stadium to another.
7. It can be P8, P10, P16, P20 and P25
Specifications :
| outdoor DIP P25 | |||||
| Resolution/mm | 25 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 1600/m² | ||||
| Module resolution | 8x8 | ||||
| Module size/mm | 200x200MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Payment terms:
T/T in advance, 30% deposit and the balance 70% will be paid before shipment.
Delivery time:15-20days
Warranty time: 3 year,offer the free spare parts(module & power supply) in advance.After guarantee term,still supply spare parts with charging only materials cost.
Packing:Standard wooden case packing free,flight case packing
Contact Person: Lillian seori
Tel: +8619386814677
