Customized HD P2 Indoor Advertising LED Display Front / Back Service
Product Description:
1. Error detection and monitoring: It can automatically monitor the internal temperature, voltage, cooling fan, etc., and automatically detect errors.
2. Energy saving: Low current, high brightness lamp beads, equipped with PFC switching power supply, saving 30% of electricity.
3. Color correction: Support point-by-point correction to ensure the consistency of LED color and brightness, and the new screen has no color difference.
4. High-quality LED: Adopt DIP346 LED, with excellent anti-static ability and UV protection performance; waterproof grade IP65, available all day long.
5. Dual backup: Power supply and system dual backup are optional, with reliable performance.
6. High refresh rate, high grayscale: using PWM driver IC, up to 16bit, refresh rate greater than 1000HZ, still maintain high grayscale under low brightness
7. Front maintenance, easy operation
8. Ultra-long service life > 100,000 hours
9. Clear and realistic image quality
10. Automatic brightness adjustment
11. VGA, Video, AVI, MOV, MPG, DAT, VOB and other file formats are comprehensive
12. Unique exhaust fan design, good heat dissipation performance.
Specifications :
| outdoor DIP P2 | |||||
| Resolution/mm | 2 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 250000/m² | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 128x128mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Competitive Advantage:
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 3 years free maintenance.During this time, we will replace or repair our goods for free if there is something wrong with them.
2. 7 days a week, 18 hours a day on-line technical support for any clients by E-mail, call, Skype or other ways for free.
3. Free training for customers in factory which contains the operation training and maintenance training in the factory.
4. Local Installation Guidance Service. We also will send our engineers to your country by negotiation
FAQ
Q1: How to help client choose suitable display?
A1:
(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control
Q2: What about your technical support?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.
Q3: What's the control system?
A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.
Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.
Q5: What's your payment method?
A5: Our payment method is T/T 30% as deposit, balancing before delivery.
