Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P1.923 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 4000-5000 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 1.923 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/32 Scanning | Module Size: | 246x246mm |
| Cabinet Size: | 492x492mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum/iron |
| Warranty: | 2-3 Years | IC: | MB5124/MB5024 |
| Highlight: | indoor led display screen,indoor led billboard |
||
Indoor P1.923 LED panel ,full color P1.923 LED advertising screen,RGB P1.923 display
Description:
246x246mm LED module
492x492mm LED panel cabinet
RGB full color LED display system
Kinglight LEDs,G-energy LED driver
Introduction:
1. Outdoor full-color LED large screen series, ultra-high pixel density, presenting a higher definition picture effect.
2. High cost performance, while meeting your high-definition picture quality needs, it has a good cost performance, greatly reducing your investment cost;
3. High efficiency: large-screen LED products use ultra-bright low-power drive LEDs, saving more than 20% energy, and the PFC circuit design combines temperature control, display control, brightness control and other technologies to achieve energy saving for the entire machine;
4. High protection level: unique chassis design, in line with IP protection standards, can be used for outdoor installation;
5. Standardized design: chassis, modules and other components adopt standardized design, different products are compatible, and the degree of standardization is high, which provides great convenience for production and maintenance;
Products Series:
Small pixel :P1.5--P1.667--P1.875--P1.9--P1.923--P2--P2.5--P2.98--P3--P3.91
Outdoor pixel series :P3.91--P4--P4.81--P5--P5.95--P6--P6.25--P6.67--P8--P10--P10.66--P16
Indoor pixel series:P3.91--P4--P4.81--P5--P5.95--P6--P6.25--P7.62--P10--P12.5
Advantages
Special heat dissipation design inside and outside the chip;
The driver IC has strong heat dissipation capability inside and outside;
The cover and casing are made of die-cast aluminum to improve the heat dissipation effect, and the driver IC is equipped with heat dissipation material outside;
Plus a high-efficiency power supply to reduce heat generation;
Specifications :
| outdoor DIP P1.923 | |||||
| Resolution/mm | 1.923 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 270420/m² | ||||
| Module resolution | 128x128 | ||||
| Module size/mm | 246x246mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/30 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
FAQ
Q1: How can I select your product?
Firstly you need to tell us your requirement such as the viewing distance, size, installation height, and some other details for the LED screen that you want. And then we will give you a recommendation.
Q2:What if I don't know how to install the screen?
1. We will provide your details drawing for installation led screen, But you need provide us on-site picture for installation
place, and we can guide on line.
2. Training 2 people in the factory.
3. We can send our engineers to your country to guide how to install the screen.
Q3:What is the minimum order quantity?
Qty: 1 unit. Different order quantity different price.
Q4:I would like to ask you if it's possible to have my logo on the product.
Logo printing service is available for mass order based on our M.O.Q
Q5:What if I don't know how to maintain the screen?
We will provide you the operation manual, software when you place the order and also we can remote to help you to adjust the software by teamviwer.
Q6: How to deliver the my goods?
It denpens on your budget and time you need the led screen. Regularly, if the quantity is less, we guggest to deliver by air, otherwise by sea to save the costs.
Q7: How about your warranty?
We provide 3 year warranty for all of our products and supply life-time maintenance.
Q8: What kind of packaging do you provide?
We provide flight case, wooden case and carton.
Q9: How long will it take me to get the product?
We will send the goods as quick as possible, but oftenly it will take 1-2 weeks to get the goods according to the distance ,and some other necessary processes.
Q9: What kind of certification do you get?
We have ISO9001 Quality Control certification. Also CE/ROHS/FCC/CCC etc for different countries’ market.
