Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel

Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel

  • Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel
  • Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel
  • Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel
  • Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel
Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P6
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meters
Price: negotiation
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Resolution/mm: 6 Pixel Configuration: 1R1G1B
Scanning Mode: 1/8 Scanning Module Size: 192x192
Cabinet Size: 960x768mm/576x576mm Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising,stage Background Material: Aluminum
Warranty: 3-5 Years
Highlight:

led digital billboards

,

led advertising billboards

LED Display Rental Service P6 Full Color LED video wall panel Die Casting Indoor Rental LED





Introduction:



SMD Full Color LED Display for Commercial Advertising Outdoor P6 LED TV Wall Panel

LED display applications:



LED display, also known as led screen, led TV wall or led sign, with its unique advantages gradually replaced the traditional billboards, light boxes, etc. LED display advertising has become a new force in the media industry.



Traditional advertising can only display pictures, while LED display/led video wall/led screen can be a perfect combination of text, pictures, video, sound, with high resolution, high brightness, full-color and so on! LED display advertisement picture is not only easy to attract the attention of pedestrians, but also easy to remember, which can produce a greater advertising effect.



LED display screen is widely used in media advertising, transportation, security, real estate, stage background and other fields,

Real estate, stage background and other fields.



Factory Introduction:



SCX is specialized in researching and manufacturing LED displays, which are created and grown with the development of information technology. It has the advantages of long lifespan and high efficiency of photoelectricity conversion, and it is far ahead in the LED display industry. Meanwhile, in daily life, such as finance, securities, stations, airports, supermarkets, etc., as a result of digital-to-analog conversion, LED displays have been popularized and widely used; in live broadcasting programs in sports stadiums, especially in directional instructions on highways, which are of great significance to drivers; LED displays are also indispensable for live performances, evenings, and advertisements, and it is a visual revolution. All these examples show that LED displays are indispensable for life, work and entertainment.



Specifications :



outdoor SMD P6
Resolution/mm 6
Pixel configuration 1R1G1B
Pixel density/pixels/m² 43222/m²
Module resolution 27778
Module size/mm 192x192mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/13 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





Products Advantages:
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps
3) Service advantage: Better service at same situation, better cooperation at same service





Products function introduction:
1) High intensity and can be adjusted, so can meet the request of the customers according the environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light
3) To pictures and character, have clear, exquisite and real display effect
LED Curtain Screen
4) Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
6) Usually apply for physical sports, advertisement, bank, stock exchange, station, port, indoor P6 display etc







Our service:
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information





Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 0

Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 1Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 2Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 3Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 4Die-Cast Aluminum LED Billboard Rental Service P6 Full Color LED Video Wall Panel 5



FAQ



1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3.36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days
