HD Waterproof LED Screen Outdoor 192192 Size 3232 Resolution Street Advertising And Shopping

Brand Name:	Shichuangxinke
Model Number:	SCXK-P6
MOQ:	1 square meters
Price:	USD400-1600per square meters
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

China ,Guang Dong

Certification:

CE RoHS FCC CCC TUV UL

Resolution/mm:

Pixel Configuration:

1R1G1B

Scanning Mode:

1/8 Scanning

Module Size:

192x192

Cabinet Size:

960x768mm/576x576mm

Certificates:

CE RoHS FCC CCC UL

Application:

Stadium,airport,shopping Mall,street Advertising,stage Background

Material:

Aluminum

Warranty:

3-5 Years

Packaging Details:

wooden box flight case, wooden case, carton, it is up to you.

Highlight:

advertising led display board

advertising led billboard

Product Description

HD High brightness waterproof outdoor LED video wall screen P6 Outdoor Rental LED Display

Our advantage:

1) Manufacturer with over 13 years of experience in electronics and PCB assembly.

2) With more than 400 employees.

3) 6 sets of high-speed SMT machines, 6 sets of Yamaha SMT machines, 2 sets of AOI test equipment, etc..

4)10 production lines.

5) 6S management.

6) ISO9001:2008 and ISO14001:2004 certified and CE/RoHS/FCC certified.

Applications:

Commercial advertising outdoor led display for mobile media, outdoor led display for stadium hoardings, outdoor led display module for mobile trailers, outdoor led display for shopping malls for signage, outdoor led display for banks and stock exchanges for exchange rates, outdoor led display for trains and buses for information and instructions, outdoor led display for airports, Telecom outdoor led display system.

What We Do:

We offer you the possibility of broadcasting advertisements on our screens, a unique advertising medium that combines the advantages of outdoor and television advertising.
This kind of advertising is very important if you want to create and support the image of your company or promote the sale of your products. A wide range of sizes are available: outdoor displays, indoor displays, semi-outdoor displays. There are also full-color, two-color and single-color for you to choose from. Customer-designed sizes are also accepted.

Specifications :

outdoor SMD P6
Resolution/mm	6
Pixel configuration	1R1G1B
Pixel density/pixels/m²	43222m²
Module resolution	27778
Module size/mm	192x192mm
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>7500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/13 SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Our service

1. Your inquiry related to our products or price will be replied in 24hrs

2. OEM&ODM, any your customized lightings we can help you to design and put into product

3. Distributoership are offered for your unique design and some our current models

4. Protection of your sales area, ideas of design and all your private information

5. Top quality+Reasonable price+Responsible After Service=Successful & Win
HD Waterproof LED Screen Outdoor 192*192 Size 32*32 Resolution Street Advertising And Shopping 0

Trade Terms

1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery

3. Shipping freight are quoted under your requests

4. Shipping port: Shenzhen, Mainland China

5. Warranty time: 2-3years
6. Delivery time: 3-12working days

We are a Chinese LED display screen manufacturer.Some of our primary products are sports stadium LED display,square LED screen,giant LED video wall,airport LED display panel,advertising LED billboard,Mobile led rental display,Stage LED display board,wall large LED display,exhibitions,shopping malls,and more.As a result,our outdoor and indoor LED display are favored by customers in many countries,

Such as : UK,Italy,Germany,USA,Spain,Singapore,Brazil,and so on.Please contact us for more detailes information on our LED display screens,we can meet the international demand for our high quality indoor led display,outdoor led display,rental led display,and creative led display.We look forward to hearing from you!

HD Waterproof LED Screen Outdoor 192*192 Size 32*32 Resolution Street Advertising And Shopping 1

FAQ:

Q1: What's the warranty of your LED Display Screen ?

A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?

A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: Whats your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
Our average Production time is 16 days, after receiving the deposit.

Q4: What's the control system?

A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.
For asynchronous control: We use ONBON or XIXUN control system.

Q5: How can you ensure the led display product quality?

A5: Our led display screen quality is our core competence, for 8 years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you .

Welcome to visit our website and inquire us more info,waiting for you all the time!!!
