Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD1900-2100 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 4 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/8 Scanning | Module Size: | 256x128MM |
| Cabinet Size: | 512x512MM | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | led full color screen,indoor led billboard |
||
Aluminum Wedding P4 Led Full Color Display / Indoor Led Screen Video Wall
Introduction
The company has a group of highly qualified professional and technical personnel and advanced modern and sophisticated production equipment, and implements strict quality management, so that each LED module, LED display, power supply, video processor, LED display and other products become market-competitive products. From the purchase of raw materials to production, assembly and testing, we strictly follow the ISO9001:2000 international quality management system to ensure product quality.
We strictly follow the ISO9001:2000 international quality management system to ensure product quality. The products have passed ISO14001:2004 international environmental assurance system certification and European CE certification.
Specifications :
| outdoor SMD P4 | |||||
| Resolution/mm | 4 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 62500/m² | ||||
| Module resolution | 256x128 | ||||
| Module size/mm | 512x512MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
FAQ
Q1: Can you provide OEM or ODM service?
Yes, our company specializes in OEM and ODM services with excellent R&D team, perfect quality and lighting solutions, just tell us what you think.
Q2: What kind of packaging is usually used for this product?
Usually we provide air box packaging (wooden box and flight case are available)
Q3: Can I print my logo on the lamps?
A: Yes, we can print your logo on the lamps for free.
Q 4: Do you offer a warranty on your products?
A: We offer a three-year warranty. The defective rate of our products is less than 0.2%.
Q 5: How long does it take to produce after an order is placed?
A: It depends on the quantity of the order. Most online wholesale orders are shipped within 3-5 days after payment is received.
Q 6: What payment methods do you accept for full orders?
We offer a variety of payment methods including PayPal, Visa, MasterCard, Alibaba Trade Assurance, Western Union, and Wire Transfer (T/T)
after-sale service:
1. Lifetime free maintenance and upgrades.2. Complaint response time does not exceed 24 hours; maintenance guidance and problem solutions are provided within 48 hours.3. Customer satisfaction tracking report.4. Free technician training.5. Free full set of documents, including installation guide, software operation manual, simple maintenance manual and control system software CD, etc.6. Special services for large projects, such as stadiums, exhibitions, squares, etc.
