Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P12 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, D/A, D/P, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 12 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/4 Scanning | Module Size: | 192x192mm |
| Cabinet Size: | 960x768mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | full color led signs outdoor,full color outdoor led display |
||
Energy Saving 12mm Dip Giant Waterproof Led Display Rgb 192x192 Led Module
Product Series:
1.Indoor LED Display: P1.6,P1.9,P2.5,P3, P4, P5, P6, P7.62, P8, P10, P12
2. Outdoor LED Display: P6, P6.25, P6.94, P7.62, P8.928, P10, P12, P12.5, P14, P16, P20, P25 ,P31.25
Features:
Trailer video LED screen has the special advantage of being movable, which is popular in street advertising and park advertising.
Easy installation saves labor cost and time.
High brightness >7500 nits, the display is clearly visible even in direct sunlight during daytime.
With light sensor, it can automatically adjust the brightness to make the brightness suitable for human eyes, saving electricity cost and more environmentally friendly.
UV protection mask, IP65 waterproof design, completely outdoor use.
Large viewing angle, full color, high color uniformity, clear image, bring you realistic audio-visual effect.
Epistar, Silan, Cree, Nichia and other LED chips are available.
ETL, CE, EMC, TUV, ISO, ROHS, SO 14001, ISO 9001 certified.
P4, P5, P6, P8, P10, P12, P16, P20, P25 and other indoor and outdoor SMD, DIP are available.
Widely used in gas stations, bus stations, shopping malls, plazas, stadiums, street advertising, restaurants, stores, etc.
Provide NOVA, DBSTAR, LINSN, COLORLIGHT LED control system.
Provide 3G, WIFI, USB, remote control system.
Specifications :
| outdoor DIP P12 | |||||
| Resolution/mm | 12 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 6944/m² | ||||
| Module resolution | 16x16 | ||||
| Module size/mm | 192x192MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our Service
Could provide LED display project support and do investigation in local places since our customers start the LED display project budget.
Customized LED screen software and hardware products will be provided base on customers’ requirements.
Provide LED screen technical training (factory or on-site) for different customers.
Drawings like steel structure drawing, connection drawing, etc. can be provided after the order.
Timely online services are provided whenever there is software operational problems and we’ll solve problems as soon as possible in working with our customers.
Advantage
1) Displaying video motion pictures in high definition
With 4,096 steps of brightness control for each RED, GREEN and BLUE color,
our system is designed to provide pictures quality similar to that of analog formula, without losing image data.
2) Displaying multi(natural) colors
With 4,096 color grades of each RED, GREEN and BLUE color, our system is designed to
display multi-colors amounting 68.7 billion on the screen.
3) Windows based operating software
Our system is designed to be operated with MS Windows.
4) Providing delicate brightness adjustment
Our system is designed to provide delicate brightness adjustment(by each 0.025% steps)
5) Providing automatic brightness adjustment
Our system is designed to provide automatic brightness adjustment according to
the change of ambiance brightness.
6) Screen size adjustment
Our system is designed to adjust screen size not only to the standard ratio of 4 : 3 or 16 : 9
but also specific size as you want to use
