Place of Origin: | China ,Guang Dong |
Brand Name: | Shichuangxinke |
Certification: | CE RoHS FCC CCC TUV UL |
Model Number: | SCXK-P12 |
Minimum Order Quantity: | negotiation |
---|---|
Price: | negotiation |
Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after deposit payment received |
Payment Terms: | L/C, T/T, Western Union, D/A, D/P |
Supply Ability: | 5000sqm per month |
Resolution/mm: | 12 | Pixel Configuration: | 1R1G1B |
---|---|---|---|
Scanning Mode: | 1/4 Scanning | Module Size: | 192x192mm |
Cabinet Size: | 960x768mm | Certificates: | CE RoHS FCC CCC UL |
Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
Warranty: | 3-5 Years | ||
Highlight: | full color outdoor led display,outdoor full color led screen |
Wall Mounted Dip12 Hanging Advertising Led Display Stage Great waterproof
Introduction
Adjustable foot cups ensure consistent cabinet height;
Perfect visual effect;
Energy saving: 50% less energy than traditional monitors;
RGB high grayscale processing, can display any real color;
Energy saving: more than 50% energy saving than traditional display;
LED module is connected to the bezel by magnet attachment;
DIP technology, high brightness. Adopting DIP technology, high brightness, even if directly facing strong sunlight, can keep the display content clearly visible;
Constant current IC driver;
High brightness and waterproof function for all weather conditions;
Why Choose Us:
No MOQ;
Competitive price as stocks and lower marketing expense;
We ensure that our products are the CE certified, ROHS compliant, FCC identified and passed the system of ISO 9001;
Provide promotion activity;
On time delivery + patient after-sales service;
We are Professional manufactory of LED Display for more than 7 years in Shenzhen China.We have 9000 square meters of production base, 400 employees, enough for any orders;:
Specifications
outdoor DIP P12 | |||||
Resolution/mm | 12 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 6944/m² | ||||
Module resolution | 16x16 | ||||
Module size/mm | 192x192MM | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >7500cd/㎡ | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/4 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Our Service
Could provide LED display project support and do investigation in local places since our customers start the LED display project budget.
Customized LED screen software and hardware products will be provided base on customers’ requirements.
Provide LED screen technical training (factory or on-site) for different customers.
Drawings like steel structure drawing, connection drawing, etc. can be provided after the order.
Timely online services are provided whenever there is software operational problems and we’ll solve problems as soon as possible in working with our customers.
FAQ
Q1: How to help client choose suitable display?
A1:
(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control
Q2: What about your technical support?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.
Q3: What's the control system?
A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.
Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.
Q5: What's your payment method?
A5: Our payment method is T/T 30% as deposit, balancing before delivery.
