Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable

Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable

  • Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable
  • Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable
  • Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable
  • Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable
Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P20
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Resolution/mm: 20 Pixel Configuration: 1R1G1B
Scanning Mode: Static Full Color Module Size: 320x160mm
Cabinet Size: 1280x960mm Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising Material: Aluminum
Warranty: 3-5 Years
Highlight:

full color led signs outdoor

,

full color outdoor led display


P20 Steel Outdoor Led Video Display Billboard Advertising Wall Front Serviceable Structure


Introduction:

Since its establishment in 2009, our company has been committed to the production and development of SMD LED displays. So far, our company has won the favor of many customers with our rich experience and stable quality in the field of SMD screen!

The quality of our products is undoubtedly recognized by many customers, but this is not enough. Our perfect service has won the long-term cooperation of many customers, which is what we are most proud of. Our sales elites are professionally trained and familiar with the basic knowledge of our products and display control systems. Once you have any problems before or after the sale, they will provide you with solutions at the first time and give you the most reasonable suggestions to save your time to the greatest extent.



Features

.High brightness, adjustable, fully meet the needs of various working environments.
· Soft mask and protective pillow protect players and LED screen itself.
· Adjustable angle: large viewing angle covers most audiences and cameras: eye-catching, infinite commercial value.
· All raw materials are strictly tested for high/low temperature and high humidity, anti-ultraviolet, anti-corrosion.
· IP65 protection grade, durability enables the screen to work in all outdoor weather conditions.
· Application: especially suitable for football/cricket fields and other sports fields.


Specifications :

outdoor DIP P20
Resolution/mm 20
Pixel configuration 1R1G1B
Pixel density/pixels/m² 2500/m²
Module resolution 16x8
Module size/mm 320x160mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode static full color
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%


Advatanges:


1) Displaying video motion pictures in high definition
With 4,096 steps of brightness control for each RED, GREEN and BLUE color,

our system is designed to provide pictures quality similar to that of analog formula, without losing image data.
2) Displaying multi(natural) colors
With 4,096 color grades of each RED, GREEN and BLUE color, our system is designed to

display multi-colors amounting 68.7 billion on the screen.
3) Windows based operating software
Our system is designed to be operated with MS Windows.
4) Providing delicate brightness adjustment
Our system is designed to provide delicate brightness adjustment(by each 0.025% steps)
5) Providing automatic brightness adjustment
Our system is designed to provide automatic brightness adjustment according to

the change of ambiance brightness.
6) Screen size adjustment
Our system is designed to adjust screen size not only to the standard ratio of 4 : 3 or 16 : 9

but also specific size as you want to use


Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 0
Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 1Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 2Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 3Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 4

Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 5

Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 6Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 7Iron Box Screen/Die-Casting Aluminum Box P20 Outdoor LED Video Display Advertising Wall Outside Wall Maintainable 8




FAQ



Q1: Can you provide OEM or ODM service?

Yes, our company specializes in OEM and ODM services with excellent R&D team, perfect quality and lighting solutions, just tell us what you think.



Q2: What kind of packaging is usually used for this product?

Usually we provide air box packaging (wooden box and flight case are available)



Q3: Can I print my logo on the lamps?

A: Yes, we can print your logo on the lamps for free.



Q 4: Do you offer a warranty on your products?

A: We offer a three-year warranty. The defective rate of our products is less than 0.2%.



Q 5: How long does it take to produce after an order is placed?

A: It depends on the quantity of the order. Most online wholesale orders are shipped within 3-5 days after payment is received.



Q 6: What payment methods do you accept for full orders?

We offer a variety of payment methods including PayPal, Visa, MasterCard, Alibaba Trade Assurance, Western Union, and Wire Transfer (T/T).
